OM-1754 4-7 1303-001 1.3.1 Scrap Box Cleaning Intervals Example for Each T ype of T ape Feeder T ype 8 mm Dual 12 / 16 mm T ape Width (mm) 8 12 16 Pithe (mm) 2 4 8 Thickness (mm) 0.4 0.5 0.7 1.1 2.5 5 Material Paper Embo…
OM-1754
4-6
Unit Name
Inspection, Cleaning,
and Lubrication Spots
Work
Cycle of Maintenance
Daily Weekly Monthly
Every
3 months
Every
6 months
Yearly
3.2.5
Traverse Cart
Pallet Receiver Inspection
Linear Guide Lubrication
Elevator Clamper Lubrication
Positioning Pin Lubrication
Pallet Chuck Lubrication
Groove on Feeder Base Cleaning
Upper Surface of Feeder
Base
Cleaning
Reel Box Cleaning
Scrap Box Cleaning
3.2.5.1
Cutter Unit
Cutter Box Inside Cleaning
Linear Guide Lubrication
Flat Ring
Replacement
Fluorine Sheet
Replacement
Urethane Clamp
Replacement
TD5
1303-001
1.3 Items for Periodic Maintenance
OM-1754
4-71303-001
1.3.1 Scrap Box Cleaning Intervals Example for Each Type of Tape
Feeder Type 8 mm Dual 12 / 16 mm
Tape Width
(mm)
8 12 16
Pithe (mm)
2 4 8
Thickness
(mm)
0.4 0.5 0.7 1.1 2.5 5
Material
Paper Emboss
Conditions
Calculated based on the High-Speed Head
(70000 CPH)
Calculated based on the
Multi-Functional Heads
(8 components / minute)
Cleaning
Intervals
12 Hr 5 Hr 3.5 Hr 2 Hr 1 Hr 24 Hr 18 Hr
Feeder Type 24 / 32 mm
Tape Width
(mm)
24 32
Pithe (mm)
16
Thickness
(mm)
5 10 16 5 10 16
Material
Emboss
Conditions
Calculated based on the Multi-Functional Heads (8 components / minute)
Cleaning
Intervals
6 Hr 3 Hr 2 Hr 4.5 Hr 2 Hr 1.5 Hr
Feeder Type 44 /56 mm 72 mm
Tape Width
(mm)
44 56 72
Pithe (mm)
28 36
Thickness
(mm)
5 10 16 5 10 16 5 10 16
Material
Emboss
Conditions
Calculated based on the Multi-Functional Heads (8 components / minute)
Cleaning
Intervals
2 Hr 1 Hr 30 Min 1.5 Hr 1 Hr 30 Min 1 Hr 30 Min 20 Min
TD6
Note
(a) The description in the above table is just an example. Decide the cleaning
intervals based on which type of tape is actually used.
(b) After cleaning the scrap box, remove the cuttings on the cart and insert the
cleaned scrap box to the end.
1.3 Items for Periodic Maintenance
OM-1754
4-8
2. Maintenance Check List
The periodic maintenance items (inspection, cleaning, lubrication, etc.) are
classied and described based on how frequently each item should be performed.
Use the tables below as check lists.
Reference
Refer to "3. Maintenance Spots" for the spots to be maintained.
2.1 Daily Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.5
Traverse Cart
Upper Surface of Feeder
Base
Cleaning - Vacuum Cleaner, Rag
Scrap Box Cleaning - -
Reel Box Cleaning - Vacuum Cleaner
TD7
2.2 Weekly Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.5
Traverse Cart
Groove on Feeder Base Cleaning ----- Vacuum Cleaner
3.2.5.1
Cutter Unit
Cutter Box Inside Cleaning - Vacuum Cleaner
Flat Ring Cleaning
TD8
2.3 Monthly Maintenance
Object Units
Inspection, Cleaning,
and Lubrication Spots
Work Grease Required Items Check
3.2.1
Pallet
Pallet Inspection
and
Cleaning
- Rag and Visual
Inspection
TD9
1303-001
2. Maintenance Check List
