OM-1754

4-9

2.4 Quarterly Maintenance

Note

DE1

: DAPHNE EPONEX GREASE No. 1

NM1

: MOLYNOC GREASE AP1

Object Units

Inspection, Cleaning,

and Lubrication Spots

Work Grease Required Items Check

3.2.1

Pallet

Rails Inspection - Scale

Upper Surface Inspection - Scale

3.2.2

Elevator Unit

Ball Screw Lubrication DE1 Oiled Rag and Brush

Frame Lower Surface Inspection

and

Cleaning

Rag

Linear Guide Lubrication DE1 Oiled Rag, Brush and

Hand Grease Gun

Belt Inspection - Visual Inspection

3.2.3

Magazine Base

Cylinder Connection

Sections

Lubrication NM1 Oiled Rag, Syringe and

Nozzle (No.18)

3.2.4

Magazine

Rack Shutter Fulcrum

Section

Lubrication NM1 Oiled Rag, Syringe and

Nozzle (No.18)

3.2.5

Traverse Cart

Pallet Receiver Inspection - Visual Inspection

Linear Guide Lubrication DE1 Oiled Rag

Pallet Chuck Lubrication DE1 Oiled Rag

3.2.5.1

Cutter Unit

Linear Guide Lubrication DE1

TD10

1303-001

2.4 Quarterly Maintenance

OM-1754

4-10

2.5 Yearly Maintenance

Note

DE1

: DAPHNE EPONEX GREASE No. 1

NM1

: MOLYNOC GREASE AP1

Object Units

Inspection, Cleaning,

and Lubrication Spots

Work Grease Required Items Check

3.2.2

Elevator Unit

Elevator Clamp Rod Inspection - Visual Inspection

3.2.3

Magazine Base

Magazine Rail Lubrication DE1 Oiled Rag, Syringe and

Nozzle (No.18)

3.2.5

Traverse Cart

Elevator Clamper Lubrication NM1 Oiled Rag, Syringe and

Nozzle (No.18)

Positioning Pin Lubrication NM1 Oiled Rag, Syringe and

Nozzle (No.18)

3.2.5.1

Cutter Unit

Fluorine Sheet

Replacement

- Screwdriver, Wrench

Urethane Clamp

Replacement

- Screwdriver, Wrench

Flat Ring

Replacement

TD11

1303-001

2.5 Yearly Maintenance

OM-1754

4-11

3. Maintenance Spots

3.1 Whole View

Notice

Any operations with a cover(s) being removed are included.

After the maintenance work, be sure to attach the cover back in place.

Traverse Cart

Elevator Shaft

Magazine Base

Cutter Unit

FD3

Reference

Refer to "3.2 Inspection, Cleaning, and Lubrication Sports" and the subsequent

items for the detailed information on the spots of each section to be maintained

and how to maintain them.

1303-001

3. Maintenance Spots
