Attachment Procedure of Tray
Procedure
(1) Put a at and rigid object (thickness: 2 mm or more) under the pallet as
shown in the gure below.
Flat and Rigid Object
(Thickness: 2 mm or more)
Pallet
FA10
Note
Make sure that the pallet is inserted correctly with its top side facing
upward.
(2) Put the tray on the rear right side of the xing.
(Make sure that there is no gap between the tray and pallet.)
(3) Hold the tray securely with the tray xing magnets.
Note
(a) Note that the tray xing magnets must be attached differently,
depending on the type or the shape of a tray.
(b) When the total mass (tray + components) exceeds "500 g", add the
tray xing magnets in the draw out direction of the pallet according to
the total mass.
(One tray xing magnet has the capability to hold the weight of
approximately 500 g.)
(c) It is recommended that up to 4 trays should be mounted when
more than one tray must be used although it is described in the
specications that up to 9 types of trays can be mounted.
(4) Check how the trays are mounted.
(Check for any positional deviation of a component, missing components,
incorrectly seated trays (trays seated aoat), and incorrect location of the tray
xing magnets.)
•
Detachment Procedure of Tray
Procedure
(1) Detach the tray xing magnets.
(2) Detach the tray from the pallet.
1303-001
3.5 Pallets
OM-1754
1-23
•
To check if the pallet is deformed or not
Put the pallet on a at surface and check if the upper surface of the pallet is
distorted or not by means of a scale, etc.
Scale
Scale
Pallet
Pallet
Distortion (Clearance)
Checking for Deformation of Pallet FA11
1303-001
3.5 Pallets
OM-1754
1-24
3.6 Tray Fixing Magnets
WARNING
Do not bring the tray xing magnet close to the area
where a pacemaker is implanted. Otherwise, the
pacemaker may be inuenced by electromagnetic
impulses of the magnet, causing the wearer to faint,
etc.
NOTICE
Do not bring a magnetic card or a watch close to the
tray xing magnets.
Otherwise, the data of the magnetic card might be cleared
or a watch, etc., may be damaged due to the strong
magnetism.
Mass :
Approx. 500 g / Magnet
Size :
Max. 330 mm × 230 mm
When the horizontal dimension of the tray exceeds "330 mm", mount a magnet
attachment to the tray xing magnet.
Magnet Attachment
Max. 330 mm
Max. 230 mm
Tray Fixing Magnet with Magnet Attachment FA12
1303-001
3.6 Tray Fixing Magnets
