Contents V ersion 3.0 ii CP-6 P AM Operation Notes:

Contents

Safety Guidelines

1. About Symbols.......................................................................................1

2. Safety Rules for All Machine Types.......................................................2

3. Safety Rules for Individual Machine Types............................................7

■ CP-series Machines .................................................................................................7

1. Using PAM.......................................................................................1-1

Purpose..................................................................................................1-1

PAM Kit...................................................................................................1-1

Overview.................................................................................................1-1

The Need for Station 11 Proper Data Calibrations .................................1-2

Notes on Using PAM ..............................................................................1-3

Procedure Overview...............................................................................1-4

Simplified Measurement Technique........................................................1-5

2. Boot-up in PAM Mode......................................................................2-1

3. ST11 Proper Data Setting Procedure..............................................3-1

Procedures.............................................................................................3-1

Using PAM at Pin Reference Boards......................................................3-4

Downloading Measurement Results to a PC..........................................3-4

4. Command Hierarchy .......................................................................4-1

5. Command Index..............................................................................5-1

6. Description of Commands...............................................................6-1

Contents

Version 3.0 i CP-6 PAM Operation

Contents

Version 3.0 ii CP-6 PAM Operation

Notes:

Safety Guidelines

1. About Symbols

To avoid injury to persons and damage to the machine, Fuji employs a number of messages

and symbols that are used in manuals and on the machines. Be sure you understand the

meanings of these symbols before reading the manual.

Safety Guidelines

Version 3.0 1 CP-6 PAM Operation

DANGER

The hazard or unsafe practice will cause severe injury or

death.

WARNING

The hazard or unsafe practice may cause severe injury or

death.

CAUTION

The hazard or unsafe practice may lead to personal injury

or damage to the machine.

To distinguish the type of hazard, the following symbols are used in combination with the

ones above.

Hazard Alert

A triangle is used to draw your attention to a hazard. The symbol inside the

triangle indicates the nature of the hazard (in this case electrical shock).

Prohibition

A circle with a diagonal line inside is used to draw your attention to an

operation that is prohibited. The symbol inside the circle indicates the nature

of the operation (in this case disassembly).

A circle with an exclamation mark is used to draw your attention to a

mandatory action. In other words, you are required to carefully carry out the

given instructions.
