Data Save: Print all of the Proper data and deviation averages for the nozzle currently designated. The printing format is as follows: Proper data Nozzle type 1 X, Y, dX, dY [1/100 mm] HEAD Proper X Proper Y Avg. dX Avg.…
Funtion Key Operation
▲: Press to move the cursor up one item.
Pressing this key with the cursor positioned in the Proper X, HEAD A,
changes the screen and moves the cursor to the Proper X, HEAD T. This
key changes the screen and moves the cursor to the Proper X, HEAD J if
the cursor is positioned in the Proper X, HEAD K.
▼: Press to move the cursor down one item.
Pressing this key with the cursor positioned in the Proper X, HEAD T,
changes the screen and moves the cursor to the Proper X, HEAD A.
Pressing this key when the cursor is positioned in the Proper X, HEAD J,
changes the screen and moves the cursor to the Proper X, HEAD K.
Proper: It is possible to move the cursor to and from the Proper X and the Proper
Y.
Data input: When selected it is possible to perform Proper data input. It is not possible
to input if the function key is pressed for a second time.
The monitor displays the following screen.
• Highlight an item and input the new value with the numerical keypad.
• Station 11 Proper data is changed and the screen returns to the regular input
screen when [CR] is pressed. The input value is deleted to allow input of a new
value if the [BS] key is pressed before the [CR] key.
• The unit of input is 1/100 mm.
Page151
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
Operation : Front
Ready
RETURN
jog
XY
C
▼ Data Save
Proper X
- 10
9
12
8
5
- 11
9
15
- 10
- 3
HEAD
HEAD A
HEAD B
HEAD C
HEAD D
HEAD E
HEAD F
HEAD G
HEAD H
HEAD I
HEAD J
Avg.dX
- 15
- 7
20
- 18
1
- 3
- 0
5
- 4
- 8
Avg.dY
- 5
- 2
13
- 8
2
- 5
- 1
26
- 19
- 4
25
- 7
10
9
12
- 14
3
- 24
- 7
16
Proper Y
No1 NOZZLE
Station 11 Proper Settings
▲ Proper
C6PM6051
6. Description of Commands
Version 3.0 6-31 CP-6 Series PAM Operation
Data Save: Print all of the Proper data and deviation averages for the nozzle currently
designated.
The printing format is as follows:
Proper data Nozzle type 1
X, Y, dX, dY [1/100 mm]
HEAD Proper X Proper Y Avg. dX Avg. dY
A -10 25 -15 -5
:::::
T-316-84
RETURN: Returns to page 150. To page 150
6. Description of Commands
Version 3.0 6-32 CP-6 Series PAM Operation
Function Key Menu
Monitor Display
Continue to display previous page.
First Status Area : Data Save
Funtion Key Operation
PRINT: Print measurement results. To Data Save 1
Down Load: Transmit measurement results. To Data Save 3
RETURN: Returns to previous page.
PRINT Down Load RETURN
Output/Save the Measurement Results PRINT Page Data Save
6. Description of Commands
Version 3.0 6-33 CP-6 Series PAM Operation
