This command is particular to the version that displays the measurement values for each
angle. Select which placement/measurement data angle to display for the nozzle type
selected on command page 140.
Function Key Menu
Monitor Display
• This display shows all nozzle and angle measurement data.
• The data displayed on the monitor represents the Avg. (average) dX, Avg. dY,
Max. dX, Max. dY, Min. dX, Min. dY, s in 1/1000 mm and Avg. dQ, Max dQ and
Min. dQ. in 1/1000°.
• The data used to calculate deviation is displayed in the middle right side of the
display.
Second Display Area : READY
First Status Area : "No.1 NOZZLE", "No.2 NOZZLE",
"No.3 NOZZLE", "No.4 NOZZLE",
"No.5 NOZZLE", "No.6 NOZZLE"
Page141
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
Operation : Front
Ready
RETURN
jog
XY
C
0 deg. 270 deg.
Avg.dX
- 13
Max.dX
26
Max.dX
- 13
3sig.X
18
Avg.dQ
- 278
Max.dQ
476
Max.dQ
- 278
3sig.Q
483
- 9
Avg.dY
19
Max.dY
- 9
Max.dY
4
3sig.Y
No.1 NOZZLE
Measurement Results
Nozzle Type
All Nozzles
All deg.
Data No.
5000
dXdY
[1/1000 mm]
dQ
[1/1000 deg]
90 deg. 180 deg. All deg.
C6PM6046
All deg. 0 deg. 90 deg. 180 deg. RETURN
270 deg.
Selecting the Angle Display SIZE Page 141
6. Description of Commands
Version 3.0 6-10 CP-6 Series PAM Operation
Function Key Operation
All deg.: Displays the placement/measurement sequence data at all angles for the
nozzle type selected on command page 140 To page 141-1
0 deg.: Displays the placement/measurement sequence data for placement at 0
degrees for the nozzle type selected on command page 140 To page 141-2
90 deg.: Displays the placement/measurement sequence data for placement at 90
degrees for the nozzle type selected on command page 140 To page 141-3
180 deg.: Displays the placement/measurement sequence data for placement at 180
degrees for the nozzle type selected on command page 140 To page 141-4
270 deg.: Displays the placement/measurement sequence data for placement at 270
degrees for the nozzle type selected on command page 140 To page 141-5
RETURN: Returns to page 140 To page 140
6. Description of Commands
Version 3.0 6-11 CP-6 Series PAM Operation
The nozzle data selected on command page 140 displays here.
Function Key Menu
Monitor Display
Second Display Area
: READY
First Status Area : "No.1 NOZZLE", "No.2 NOZZLE", "No.3 NOZZLE"
"No.4 NOZZLE", "No.5 NOZZLE", "No.6 NOZZLE"
Function Key Operation
Deviation: Displays the nozzle deviation for each axis (X, Y and Q)
To page 141-1-1
Deviat’n avg.: Displays the nozzle deviation average for each head and specified
axis (X, Y or Q) To page 141-1-2
Max/Min dev.: Displays the max/min nozzle deviation amount for each head and
specified axis (X, Y or Q) To page 141-1-3
Accuracy: Displays the nozzle accuracy (3s) for each head and specified axis
(X, Y or Q) To page 141-1-4
RETURN: Returns to page 141 To page 141-1
Page141
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
Operation : Front
Ready
RETURN
jog
XY
C
Deviat'n avg.
Avg.dX
- 13
Max.dX
26
Max.dX
- 13
3sig.X
18
Avg.dQ
- 278
Max.dQ
476
Max.dQ
- 278
3sig.Q
483
- 9
Avg.dY
19
Max.dY
- 9
Max.dY
4
3sig.Y
No.1 NOZZLE
Measurement Result
Nozzle Type
All Nozzle
All degrees
All data
5000
dXdY
[1/1000mm]
dQ
[1/1000deg]
Max/Min dev. AccuracyDeviation
C6PM6023
Deviation Deviat'n avg. Max/Min dev. Accuracy RETURN
Specific Nozzle Data Display
No.1 ~ No.6 NOZZLE
Page
141-1
6. Description of Commands
Version 3.0 6-12 CP-6 Series PAM Operation
