Function Key Menu Monitor Display Continue to display previous page. First Status Area : Data Save Funtion Key Operation PRINT: Print measurement results. To Data Save 1 Down Load: Transmit measurement results. To Data S…

Data Save: Print all of the Proper data and deviation averages for the nozzle currently

designated.

The printing format is as follows:

Proper data Nozzle type 1

X, Y, dX, dY [1/100 mm]

HEAD Proper X Proper Y Avg. dX Avg. dY

A -10 25 -15 -5

:::::

T-316-84

RETURN: Returns to page 150. To page 150

6. Description of Commands

Version 3.0 6-32 CP-6 Series PAM Operation

Function Key Menu

Monitor Display

Continue to display previous page.

First Status Area : Data Save

Funtion Key Operation

PRINT: Print measurement results. To Data Save 1

Down Load: Transmit measurement results. To Data Save 3

RETURN: Returns to previous page.

PRINT Down Load RETURN

Output/Save the Measurement Results PRINT Page Data Save

6. Description of Commands

Version 3.0 6-33 CP-6 Series PAM Operation

Function Key Menu

Monitor Display

Press function key number 2 in the print mode.

First Status Area : PRINT

Funtion Key Operation

EXECUTE: Print measurement results.

RETURN: Returns to Data Save. To Data Save

RETURNEXECUTE

Output/Save the Measurement Results PRINT Page Data Save-1

6. Description of Commands

Version 3.0 6-34 CP-6 Series PAM Operation
