This function displays the minimum and maximum deviation for the X, Y and Q- axes for each head (A~T). The X, Y, and Q-axis deviation averages for all of the sequences placed with the nozzle type specified on command pag…
Output Format (deviation average per axis)
With [All deg.] selected:
Average Deviation Nozzle type 1
All deg.
dX, dY [1/1000 mm] dQ [1/1000 deg]
Avg. dX Avg. dY Avg. dQ
HEAD A -13 -9 -278
↓
HEAD T -1 6 214
With [0 deg.], [90 deg.], [180 deg.], or [270 deg.] selected:
Average Deviation Nozzle type 1
dX, dY [1/1000 mm] dQ [1/1000 deg]
0 deg. 90 deg. 180 deg. 270 deg.
HEAD dX dY dQ dX dY dQ dX dY dQ dX dY dQ
A 21 6 -34 20 -3 -152 14 0 -56 17 5 -166
↓
T 18 2 14 14 0 -275 14 -1 -47 15 3 -56
6. Description of Commands
Version 3.0 6-18 CP-6 Series PAM Operation
This function displays the minimum and maximum deviation for the X, Y and Q- axes
for each head (A~T).
The X, Y, and Q-axis deviation averages for all of the sequences placed with the nozzle
type specified on command page 141 will display after selecting "All deg.".
The X, Y and Q-axis deviation averages for all sequences placed with the selected nozzle
types and placement angles are displayed when [0 deg.], [90 deg.], [180 deg.], or [270
deg.] are selected.
If a vision processing error occurs while reading placement coordinates, that sequence
data cannot be used for the calculations.
A "0" displays for the placing positions not yet calculated.
Function Key Menu
Monitor Display
Second Display Area
: READY
First Status Area : MAX/MIN DEV.
Page141
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
ST 1N
ST 2N
ST 3N
ST 6N
ST 7N
ST 8N
ST10N
ST11N
3D 5Er****
3D 5Er****
3D 5Er****
3D 5Er****
3D 5Er 0
3D 5Er 0
3D 5Er 0
3D 5Er 0
Operation : Front
RETURN
Ready
jog
XY
C
Head
STATUS
P Mode
Recovery
T Mode
PAM Mode
Product
E Pass
Joint
MAX/MIN DEV.
Axis
C6PM6029
Axis RETURNHead
Specific Nozzle Max/Min Deviation Display Max/Min Dev. Page
141-1-3
6. Description of Commands
Version 3.0 6-19 CP-6 Series PAM Operation
Function Key Operation
Axis: This displays the X, Y and Q-axis minimum and maximum deviation values
for all of the heads (A ~T).
The monitor displays what is shown below.
• The data displayed is for the nozzle and angle(s) listed in the upper right region of
the 1st display area under the heading "Nozzle Type".
• The unit of measurement displayed is 1/1000 mm for the Min/Max dX, dY and
1/1000° for the Min/Max dQ.
• The data used to calculate Min/Max deviation amount is displayed in the middle
of the right side in the 1st display area.
• The current display is sent to the printer if [Data Save] is selected. The output is
shown below.
• When [RETURN] is pressed, the screen is cleared and the monitor will return to
the initial display where [Axis] or [Head] can be selected.
Page141
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
Operation : Front
Ready
RETURN
jog
XY
C
Data Save
Max.dX
26
Max.dX
- 13
Max.dQ
476
Max.dQ
- 278
19
Max.dY
- 9
Max.dY
MAX/MIN DEV.
Max/Min Deviation for Each Axis
Nozzle Type
No. 1
All Deg.
Data
5000
dXdY
[1/1000 mm]
dQ
[1/1000 deg]
C6PM6048
