This displays the measured data. It also selects the nozzle type from the following data.
Function Key Menu
Monitor Display
• This display shows all nozzle and angle measurement data.
• The data displayed on the monitor represents the Avg. (average) dX, Avg. dY,
Max. dX, Max. dY, Min. dX, Min. dY, s in 1/1000 mm and Avg. dQ, Max dQ and
Min. dQ. in 1/1000°.
• The data used to calculate deviation is displayed in the middle right side of the
display.
Second Display Area : READY
First Status Area : DATA
Page140
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
Operation : Front
Ready
RETURN
jog
XY
C
SIZE
Data Save
Avg.dX
- 13
Max.dX
26
Max.dX
- 13
3sig.X
18
Avg.dQ
- 278
Max.dQ
476
Max.dQ
- 278
3sig.Q
483
- 9
Avg.dY
19
Max.dY
- 9
Max.dY
4
3sig.Y
DATA
Measurement Result
Nozzle Type
All Nozzle
All degrees
All data
5000
dXdY
[1/1000 mm]
dQ
[1/1000 deg]
C6PM6020
SIZE PRINT RETURN
Displaying the Data
Data display
Page 140
6. Description of Commands
Version 3.0 6-8 CP-6 Series PAM Operation
Function Key Operation
SIZE: This selects the nozzle type
The message “Nozzle No. ? “ displays on the screen. Enter the nozzle
number you want displayed. To page 141
Data Save: This prints or saves the data currently displayed on the monitor.
The print format is shown below.
Total data dx [1/1000 mm] dy [1/1000 mm] dQ [1/1000 deg]
Average Deviation Avg. dX: -13 Avg. dY: -9 Avg. dQ: -278
Maximum Deviation Max. dX: 26 Max. dY: 19 Max. dQ: 476
Minimum Deviation Min. dX: -13 Min. dY: -9 Min. dQ: -278
Placing Accuracy 3sig. X: 18 3sig. Y: 4 3sig. Q: 83
RETURN: Return to page 100 To page 100
6. Description of Commands
Version 3.0 6-9 CP-6 Series PAM Operation
This command is particular to the version that displays the measurement values for each
angle. Select which placement/measurement data angle to display for the nozzle type
selected on command page 140.
Function Key Menu
Monitor Display
• This display shows all nozzle and angle measurement data.
• The data displayed on the monitor represents the Avg. (average) dX, Avg. dY,
Max. dX, Max. dY, Min. dX, Min. dY, s in 1/1000 mm and Avg. dQ, Max dQ and
Min. dQ. in 1/1000°.
• The data used to calculate deviation is displayed in the middle right side of the
display.
Second Display Area : READY
First Status Area : "No.1 NOZZLE", "No.2 NOZZLE",
"No.3 NOZZLE", "No.4 NOZZLE",
"No.5 NOZZLE", "No.6 NOZZLE"
Page141
CP_6.PROGRAM
000000000000
000000000000
Prod 00000 Sche 00000
P1.00 off line
Operation : Front
Ready
RETURN
jog
XY
C
0 deg. 270 deg.
Avg.dX
- 13
Max.dX
26
Max.dX
- 13
3sig.X
18
Avg.dQ
- 278
Max.dQ
476
Max.dQ
- 278
3sig.Q
483
- 9
Avg.dY
19
Max.dY
- 9
Max.dY
4
3sig.Y
No.1 NOZZLE
Measurement Results
Nozzle Type
All Nozzles
All deg.
Data No.
5000
dXdY
[1/1000 mm]
dQ
[1/1000 deg]
90 deg. 180 deg. All deg.
C6PM6046
All deg. 0 deg. 90 deg. 180 deg. RETURN
270 deg.
Selecting the Angle Display SIZE Page 141
6. Description of Commands
Version 3.0 6-10 CP-6 Series PAM Operation
