2-50

2.4.4.2.

Rear Panel 分解图及零件表

2-51

附加装置

No. Part No. Part Name Q'ty

Service

Material

Remarks

1 FC30-005152A PLATE-REAR PANEL_SM1-FWS-201 1

2 EP07-001199A BREAKER,CIRCUIT-MCCB_BKM-B(2P-15A) 1

3 RM01-003992A RAIL-DIN RAIL_KH-TBR-2 1

4 EP07-901544 NOISE_FILTER_UF20SBS AC250V/20A 1

5 EP05-001034A CABLE CONNECTOR 1

6 EP05-001035A CONNECTOR-LAN

CONNECTOR_RJ45(KINSUN)

7 HP06-001085A FITTING-ONETOUCH FITTING_PPM06-R14 1

8 FC29-008802A HOLDER-CABLE HOLDER_OSB-16-100P;FLMS 8

9 PT03-002565A STICKER-FLMS_ELECTRIC SHOCK STICKER 1

10 PT03-002566A STICKER-FLMS_AC100V-240V STICKER 1

11 EP02-004222A CABLE-FEEDER WORKSTATION_SM1-FWE-

010

12 EP02-004223A CABLE-DOCKING CART_SM1-FWE-011 8

13 EP10-001109A CONVERTER,ELECTRIC-GENDER_SM1-FWE-

012

8 For pneumatic docking

cart(blue cover type)

14 EP02-004224A CABLE-POWER CODE_AC220V 15A 1

{TzYG|˅Gn{TzYG|˅Gn

2-52

2.4.4.3.

Case Panel 分解图及零件表
