T-Solution2_User_Guide(Chi_Ver11.3)_部分1.pdf - 第66页

{TzYG|˅Gn {TzYG|˅Gn 2-14 2.1.2.4 . ETC Assembly 分解图及零件表

2-13

附加装置

序号零件号元件名数量

1 FC30-001718A ELITE-PART_PLATE 1

2 FC09-003501A ELITE-R_STAGE_BRACKET 1

3 FC18-000980A ELITE-CLAMP 1

4 FC40-000005 REVOLVING STAGE 1

5 FC05-000340A ELITE-R_STAGE_BASE 1

6 J70691374A INDICATOR_JOINT 1

7 J61191093A DIGIMATIC SCALE 1

8 FC09-003498A INDICATOR 1

9 J66191061A R STAGE BASE 1

10 J71691172A STAGE_JOINT 1

11 J66191060A XY STAGE 1

12 J61191054A PULLS 1

13 FC30-001822A ELITE-SLIDE_INDEX 1

14 FC30-001823A SLIDE_STAGE_BASE 1

15 J71691169A INDICATOR_FIX_BRACKET 2

{TzYG|˅Gn{TzYG|˅Gn

2-14

2.1.2.4.

ETC Assembly分解图及零件表

2-15

附加装置

序号零件号元件名数量

1 AM03-011243A ELITE-CPU_BOX 1

2 FC29-000289 M3X15_PCB_SUPPORT 6

3 AM03-009556A ASSY,BOARD-SILL BD ASSY 1

4 FC09-003412A ELITE-PS_BKT 2

5 EP06-000041 PBA150F-24 1

6 FC09-003413A ELITE-CABLE_SUPPORT 1

7 FC09-003559A ELITE-CON_BKT 1

8 AM03-011313A ASSY,ELITE PRO TERMINAL ASSY 1

9 FC09-003560A ELITE-MC_BKT_F 1

10 EP07-000621 BREAKER,CIRCUIT-23811 C60A 2P C10

CP_SW

1

11 RM01-000035 RAIL UA-417 (L=100mm) 1

12 MC13-000252 SBM09-1-K1-155L-N-R-II 2

13 FC30-001717A ELITE-BASE_PLATE 1

14 HP15-000021 PLUNGER-SPJK6 1

15 FC09-003563A ELITE-INDEX_BASE 1

16 FC15-002130A ELITE-SEPERATE_COVER 1

17 FC28-000162 ELITE-FOOT 4

18 FC29-002656A ELITE-STAGE_CAM_SUPPROT 4

19 FC09-003411A ELITE_HW_BRACKET 1

20 J6503001A TIE_MOUNT 12
