The machine stops automatically once the scheduled production quantity is

produced. Refer to "Setting the Scheduled Production Quantity" in section

3.2, regarding the procedure for setting the scheduled production quantity.

During the course of production it is possible to automatically stop the

machine once the panel(s) currently on the main conveyor is completed and

unloaded from the machine.

Procedure

1. Press [Finish Current Panels] while production on the machine

is in progress.

2. Once production of the panel(s) currently being produced

(panel on the main conveyor) is finished and the panel is

unloaded from the machine, the machine will automatically

stop.

6.2 Stopping Automatically after Current

Panel Is Completed

6.1 Stopping Automatically Upon Completion

of the Scheduled Production Quantity

Chapter 6: Finishing Production

TUT-XP142-1.1E

6-2 XP-142E Operator’s Guide

Chapter 7

Maintenance

7.1 Emptying the Waste Tape Box <if so equipped> (Every 8 Hours)

7.2 Emptying the Parts Reject Box and Tray (Every Day)

7.3 Cleaning the Nozzle Interior (Every Week)

7.4 Cleaning the Gauge Chip Parts (Every Week)

7.5 Cleaning the Vacuum Pump Filter (Every Week)

7.6 Cleaning the Strobe Light Half Mirror and Prism surface

(Every Week)

7.7 Cleaning the Machine Interior (Every Week)

TUT-XP142-1.0E

7-1XP-142E Operator’s Guide

Point

Remove tape that has built up during production in the waste tape box. This

refuse must be cleared to ensure it does not interfere with parts feeding.

If the machine has a waste tape cutter, a function to notify the operator when

the waste tape box is full can be enabled. Refer to the XP-142E System

Reference manual for details.

Procedure

Pull the waste tape boxes out, then discard the waste tape (empty the waste

tape boxes).

XP1MC201E

Waste tape box

7.1 Emptying the Waste Tape Box

<if so equipped> (Every 8 Hours)

Chapter 7: Maintenance

TUT-XP142-1.0E

7-2 XP-142E Operator’s Guide
