7 Options User Manual SIP LACE F5 HM 7.3 Component barc ode Software Vers ion SR.408.xx 03/2006 US Edition 186 7.3 Com ponent b arcod e 7.3.1 Gener al With the p lacement system, a barcode s canner can be us ed to check …

User Manual SIPLACE F5 HM 7 Options

Software Version SR.408.xx 03/2006 US Edition 7.2 Nozzle changer for the 6-segment Collect&Place head

185

Fig. 7.2 - 4 Changing the magazine

(1) Spring hook

(2) Push the spring hook aside.

(3) Positioning fiducial

(4) Latching groove

PLEASE NOTE

When you insert the magazine, make sure that the side with the position fiducial points towards

the spring hook. There is a latching groove on the opposite side of the magazine. 7

Æ To insert the magazine, place the side with the groove on the tray.

Æ Push the spring hook to one side and click the entire magazine onto the carrier.

Release the spring hook.

The spring hook must latch into place.

7 Options User Manual SIPLACE F5 HM

7.3 Component barcode Software Version SR.408.xx 03/2006 US Edition

186

7.3 Component barcode

7.3.1 General

With the placement system, a barcode scanner can be used to check that the track allocation is

correct and to read component data from component reels.

Fig. 7.3 - 1 Component barcode scanner

(1) Component barcode scanner

Track allocation

Four-digit barcode strips are attached to the lateral safety screens for the purposes of track allo-

cation. The first digit is used to identify the component table (1 or 2), while the remaining three

digits specify the track number. There are also return barcodes at both ends of the barcode strip.

The barcode strips are numbered consecutively in intervals of two (1, 3, 5, 7...) and each repre-

sents 2 tracks (barcode 1 = track 1 and 2).

User Manual SIPLACE F5 HM 7 Options

Software Version SR.408.xx 03/2006 US Edition 7.3 Component barcode

187

Components

Data can be read from the component reels to compare the stock of components against the

quantity specified in the set-up file (refill check), for example.

An audible signal is given when each dataset has been read successfully.

PLEASE NOTE 7

The component barcode scanner option must be configured on the SIPLACE Pro computer.

Barcodes that start with the number 1 or 2 and are less than 5 digits long are interpreted as track

barcodes. All other barcodes (that do not start with number 1 or 2 and are more than 5 characters

long) are interpreted as component barcodes. 7

7.3.2 Technical data

Connection Station computer

Data entry via barcode scanner or keyboard

Number of characters up to 40

Not permissible Barcodes starting with a 1 or 2 and less than 5

characters long

Number of barcodes up to 6 per component

Filter for suppressing data up to 1 per barcode

Preset code types Code 39 (standard or ASCII)

Code 2 of 5, interleaved and normal,

Code 128, UPC/EAN/JAN codes

(others available upon request)
