序号 料号 部品名称 数量 规格 备注 009 NB16805004AA PLATE 1 010 NB16805025AC RAIL 1 011 NB16805006AA KEY 2 012 NB16805007AA BRACKET 2 013 NB16805008AA BRACKET 2 014 NB16805009AA COLLAR 2 015 NB168FG0501AA FLAT WASHER 4 5-10-H1 016 NB16…
5
UNLOADER
SECT.(P.C.B
SINGLE
RIGHT
TO
LEFT.
-2)
0.
Oil
012
X003
013
020
017
X005
018
X004
015
018
010
X005
018
015
A
012
016
019
X006
X007
>
Oil
020
013
X003
009
X007
X013
X004
X003
X008
1
/
1
X012
X013
、/…
X004
卜、
X012
丁
X003
尸
X003
/
X012
X003
K/012
「
X001
LX012
018
014
「
X001
(N37)
序号 料号 部品名称 数量 规格 备注
009 NB16805004AA PLATE 1
010 NB16805025AC RAIL 1
011 NB16805006AA KEY 2
012 NB16805007AA BRACKET 2
013 NB16805008AA BRACKET 2
014 NB16805009AA COLLAR 2
015 NB168FG0501AA FLAT WASHER 4 5-10-H1
016 NB16805011AA PULLEY 1
017 NB16805015AA BELT 1 0.8-8.0-1370
018 NB168F605ZZAA BEARING 12 F605ZZ
019 NB168699ZZAA BEARING 1 699ZZ
020 NB168D61S2MAA SENSOR 2 E3ZG-D61
X001 NB168SH0304 SOKET HEAD CAP SCREW 2 M3-L4
X003 NB168SH0308 SOKET HEAD CAP SCREW 12 M3-L8
X004 NB168SH0516 SOKET HEAD CAP SCREW 9 M5-L16
X005 NB168TPH0520 ROUND HEAD SCREW 2 M5-L20
X006 NB168SH0530 SOKET HEAD CAP SCREW 2 M5-L30
X007 NB168SH0820 SOKET HEAD CAP SCREW 2 M8-L20
X008 NB168SN05 SQUARE NUT 2 M5
X011 NB168SS0405 SUNK SCREW 1 M4-L5
X012 NB168FG0307 FLAT WASHER 12 3-7-H0.5
X013 NB168FG0510 FLAT WASHER 7 5-10-H2
5 UNLOADER SECT.(P.C.B SINGLE RIGHT TO LEFT.-2)
X013 NB168FG0510 FLAT WASHER 7 5-10-H2
N38
CN
双
