NB168-配件手册.pdf - 第79页
(NG®
序号 料号 部品名称 数量 规格 备注
A001 NB168NU0601 COVER SECT NUIT
A002 NB16806080AA FRAME 1
001 NB168TPC6000AA DISPLAYER 1
002 NB16806074AA BRACKET 2
003 NB16806075AA BRACKET 1
004 NB168PL05NAA SAFETY 1 PL-05N(APT)
005 NB16806057AA START BUTTON 1
006 NB16806030AA START BUTTON 1 G
007 NB16806031AA STOP BUTTON 1 R
008 NB16806032AA RESET BUTTON 1 Y
009 NB16806059AA SERVO SWITCH 1
X001 NB168PH0610 ROUND HEAD SCREW 11 M6-L10
X002 NB168SH0316 SOKET HEAD CAP SCREW 2 M3-L16
X003 NB168SH0616 SOKET HEAD CAP SCREW 9 M6-L14
X004 NB168SH0614 SOKET HEAD CAP SCREW 6 M6-L14
X005 NB168SH0412 SOKET HEAD CAP SCREW 4 M4-L12
X006 NB168SH0410 SOKET HEAD CAP SCREW 2 M4-L10
X007 NB168FG0613 FLAT WASHER 15 6-13-H2
X008 NB168FG0412 FLAT WASHER 6 4-12-H1.5
X009 NB168SW04 SPRING WASHER 2 4-7-H1.0
6 COVER SECT.(CONSOLE PANEL SECT)
N62
(NG®
序号 料号 部品名称 数量 规格 备注
001 NB16806004AA COVER 1
002 NB16806005AA COVER 1
003 NB16806011AA COVER 1
004 NB16806007AA COVER 1
045 NB16806038AA COVER 1
046 NB16806039AA COVER 1
047 NB16806065AA COVER 1
005 NB16806008AA WINDOW PLATE 1
010 NB168SJHA2AA FAN WITH MOTOR 1
X001 NB168PH0610 ROUND HEAD SCREW 41 M6-L10
X002 NB168PH0508 ROUND HEAD SCREW 18 M5-L8
6 COVER SECT.-1
N64
