Operating Instruct ions Air cushion transporting system for SIPLACE 5.4 Transporting the load 10/99 edition 30 5.4 T ranspo rting th e loa d 5 5 16 14 1 4 1 5 1 7
Air cushion transporting system for SIPLACE Operating Instructions
10/99 edition 5.3 Structure of the transport system
29
; Fully depressurize all the pressure regulators.
A Open the ball cocks to the air cushions.
S Turn the cap on the pressure regulators until the air cushion modules start to rise. Wait until
the load to be transported hovers freely and a slight flow of air emerges from beneath the
rubber bellows. All the air cushion modules must rise to the same height – whatever their load.
WARNING 5
: The operating pressure must never exceed the values shown in Tab. 6.1 - 1 and 6.3 - 1.
5
WARNING RISK OF CRUSHING 5
: Do not place hands or feet between the transported load and balancing boards or between the
load and the ground.
5
D Slowly close the main ball cock on the control unit.
Operating Instructions Air cushion transporting system for SIPLACE
5.4 Transporting the load 10/99 edition
30
5.4 Transporting the load
5
5
16
14
1
4
1
5
1
7
Air cushion transporting system for SIPLACE Operating Instructions
10/99 edition 5.4 Transporting the load
31
: Make sure that there are enough people present to move the load safely.
: Instruct these people as follows:
DANGER 5
: Follow the safety instructions and note any potential sources of danger.
5
All the air cushions must always be fully inflated.
Do not exceed normal walking pace when moving the load.
Make sure that the load does not slip off to one side while it is being moved.
The person in charge gives the instruction to start moving the load. 5
5
F Slowly open the main ball cock on the control unit.
G Make sure that all the air cushions have risen to the same height and are hovering freely.
WARNING RISK OF CRUSHING 5
: Risk of crushing: Do not place hands or feet between the transported load and balancing
boards or between the load and the ground.
5
: The person in charge gives the instruction to start moving.
H Move the load
: Take hold of the air cushion and check the position. Correct the position if necessary (if a loss
of pressure has occurred).
: The person in charge gives the instruction to stop.
: Pause or stop moving the load:
Stop the load and hold it steady.
