Air cushion t ransporting system for SIPLACE Operating Instructions 10/99 edition 6.3 Standard air cushion transporting s ystem 39 6.3 S t andard air cush ion tran sportin g syste m Fig. 6.3 - 1 Dimensions of a st andard…

100%1 / 84
Operating Instructions Air cushion transporting system for SIPLACE
6.2 Air cushion module options 10/99 edition
38
Explanatory notes:
1) Pressure in the air cushion module under full load. Conversion: 100 kPa = 1 bar
2) The air consumption is partly dependent on:
the actual load on the air cushion module and
the condition of the floor
3) Lift height (±5 mm) when fully laden
4) Supporting surface when the air cushion module is lowered
5) Cast aluminum / profiled aluminum supporting plate
6.2 Air cushion module options
– Air cushion modules with larger or smaller lift
– Air cushion modules with protective polyurethane lining
– Air cushion on a stainless steel plate for the offshore and chemical industries
– Air cushion modules for theatres and multi-purpose halls
Modul
e
type
Air cushion
type
Working
load
kg
Air
pressure
kPa
1)
Air
consumpt
ion
l/min
2)
Lift
mm
3)
Annular
surface
cm
2
Supporting
surface
cm
2
4)
A
mm
B
mm
C
mm
D
mm
E
inch
ML 8
SE 8-0,8-LP 750 300 180 10 245 30 204 21/41
5)
10 31/51
5)
1/4 / 3/4
5)
ML 12
SE 12-1,8-LP 1750 300 280 15 550 90 304 21/41
5)
10 31/51
5)
1/4 / 3/4
5)
ML 15
SE 15-2,5-LP 2500 300 550 20 860 130 380 21/41
5)
10 31/51
5)
1/4 / 3/4
5)
ML21S
ME 21S-3,5-LP 3500 210 750 25 1690 260 534 41 17 58 3/4
ML27S
ME 27S-6,0-LP 6000 210 850 35 2795 1000 684 41 24 65 3/4
ML36S
ME 36S-11-LP 11000 210 1000 50 4970 1900 914 41 30 71 3/4
ML21H
ME 21H-7,0-LP 7000 410 1300 25 1690 600 534 41 17 58 3/4
ML27H
ME 27H-12-LP 12000 430 1500 35 2795 1000 684 41 24 65 3/4
ML36H
ME 36H-20-LP 20000 400 1750 50 4970 1900 914 41 30 71 3/4
ML42H
ME 42H-30-LP 30000 400 1850 65 7760 2640 1070 41 30 71 3/4
ML48H
ME 48H-40-LP 40000 450 2000 75 8835 3600 1220 41 30 71 3/4
ML60H
ME 60H-60-LP 60000 390 2750 75 15540 6725 1500 41 31 72 3/4
Tab. 6.1 - 1 Standard air cushion module types
Highlight your own transport system 0
Air cushion transporting system for SIPLACE Operating Instructions
10/99 edition 6.3 Standard air cushion transporting system
39
6.3 Standard air cushion transporting system
Fig. 6.3 - 1 Dimensions of a standard air cushion transporting system
E
D
A
A
B
C
Operating Instructions Air cushion transporting system for SIPLACE
6.4 Air cushion transporting system options 10/99 edition
40
6
Explanatory notes:
1) When the air cushion module is positioned beneath the load, it must not be subjected
to more than the maximum admissible working load of that module (see Tab. 6.1 - 1).
2) The air consumption is partly dependent on:
the actual load on the air cushion modules and
the condition of the floor
3) Pressure in the air cushion module under full load. Conversion: 100 kPa = 1 bar
4) Cast aluminum / profiled aluminum supporting plate
5) Threaded connector for the control unit (inches)
6.4 Air cushion transporting system options
– Air cushion transporting system with 6 air cushion modules
– Control unit with remote control
– Control unit with connection for lifting cushions
– Other hose lengths available upon request
System
type
Working
load
kg
1)
Air
consumption
l/min
2)
Module
type
Air
pressure
kPa
3)
A
mm
B
mm
C
mm
D
inc
h
E
inch
5)
Control unit
type
MLS412
7000 1120 ML 12 300 304 31/51
4)
15 1/2 1 MRB 4-15
MLS415
10000 2200 ML 15 300 380 31/51
4)
20 1/2 1 MRB 4-15
MLS421S
14000 3000 ML 21S 210 534 58 25 3/4 1 MRB 4-20
MLS427S
24000 3400 ML 27S 210 684 65 35 3/4 1 1/2 MRB 4-20
MLS436S
44000 4000 ML 36S 210 914 71 50 3/4 1 1/2 MRB 4-20
MLS421H
28000 5200 ML 21H 410 534 58 25 3/4 1 1/2 MRB 4-20
MLS427H
48000 6000 ML 27H 430 684 65 35 3/4 1 1/2 MRB 4-20
MLS436H
80000 7000 ML 36H 400 914 71 50 1 1 1/2 MRB 4-25
MLS442H
120000 7500 ML 42H 400 1070 71 65 1 2 MRB 4-25
MLS448H
160000 8000 ML 48H 450 1220 71 75 1 2 MRB 4-25
Tab. 6.3 - 1 Standard air cushion transporting system types
