Station Software 708.1 / Installation Manual Ausgabe 05/2015 E dition 18 4.2 Hardware Com ponents of SIPLA CE Series X, X S, SX , DX and CA 4.2.1 Machine Computer Name SIMATIC BoxPC 627B CPU / clock frequen cy Core 2 Duo…
Station Software 708.1 / Installation Manual Ausgabe 05/2015 Edition
17
--- CPPSZD
1)
Z-bottom, CPP head
--- WPCAXI
2)
WPC5 feed axis and lift axis
--- WPCHNG
2)
WPC5 / WPC6
--- DLMHED
3)
C&P12 head
Table 4-2: Names of the subsystems
1)
as of 702.xx
2)
as of 703.xx
3)
as of 705.03
Station Software 708.1 / Installation Manual Ausgabe 05/2015 Edition
18
4.2 Hardware Components of SIPLACE Series X, X S, SX, DX and CA
4.2.1 Machine Computer
Name SIMATIC BoxPC 627B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-3: Machine computer hardware SIPLACE X-, SX- and DX-series
Name SIMATIC BoxPC 827B
CPU / clock frequency Core 2 Duo T7400 / 2.16 GHz
RAM 2 GB
Harddisk Yes
External DVD drive No
Internal DVD drive Yes
Serial interfaces 1
USB interfaces Yes
External USB hub Yes (X-series) / No (SX4)
Network 2x 100 MBit
Table 4-4: Machine computer hardware SIPLACE X-, SX- and DX-series
Station Software 708.1 / Installation Manual Ausgabe 05/2015 Edition
19
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel® Celeron® P4505 / 1.87 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-5: Machine computer hardware SIPLACE X-, X S-, SX- and DX-series
Name SIMATIC BoxPC 827C
CPU / clock frequency Intel® Core
(TM)
i3 / 2.13 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-6: Machine computer hardware SIPLACE X-, X S-, SX-, DX- and CA-series
Name I-Base ABP 402-A
CPU / clock frequency Intel® Celeron® CPU 1020E / 2,2 GHz
RAM 4 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 2
USB interfaces and external USB hub Yes
Network 2x 1000 MBit
Table 4-7: Machine computer hardware SIPLACE SX-series
