Station Software 708.1 / Installation Manual Ausgabe 05/2015 E dition 20 Name SIMATIC MicroBox 427D CPU / clock frequen cy Intel ® Core (TM) / 1,6 GHz RAM 4 GB Harddisk Yes (80 GB SSD) External DVD drive Yes Internal DVD…
Station Software 708.1 / Installation Manual Ausgabe 05/2015 Edition
19
Name SIMATIC BoxPC 627C
CPU / clock frequency Intel® Celeron® P4505 / 1.87 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-5: Machine computer hardware SIPLACE X-, X S-, SX- and DX-series
Name SIMATIC BoxPC 827C
CPU / clock frequency Intel® Core
(TM)
i3 / 2.13 GHz
RAM 2 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-6: Machine computer hardware SIPLACE X-, X S-, SX-, DX- and CA-series
Name I-Base ABP 402-A
CPU / clock frequency Intel® Celeron® CPU 1020E / 2,2 GHz
RAM 4 GB
Harddisk Yes
External DVD drive Yes
Internal DVD drive No
Serial interfaces 2
USB interfaces and external USB hub Yes
Network 2x 1000 MBit
Table 4-7: Machine computer hardware SIPLACE SX-series
Station Software 708.1 / Installation Manual Ausgabe 05/2015 Edition
20
Name SIMATIC MicroBox 427D
CPU / clock frequency Intel® Core
(TM)
/ 1,6 GHz
RAM 4 GB
Harddisk Yes (80 GB SSD)
External DVD drive Yes
Internal DVD drive No
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 1000 Mbit
Table 4-8: Machine computer hardware SIPLACE X-Series S
4.2.1.1 Machine Computer/Coplan Computer with 3D Coplan Sensor
The coplanarity module with the 3D coplan sensor (type 37) can be optionally installed in the
SIPLACE X2, X3, X4 and SX1/SX2 (V2) placement machines (item no. [00119919-xx] for X-series,
item no. [00519919-xx] for SX-series).
Station Software 708.1 / Installation Manual Ausgabe 05/2015 Edition
21
4.3 Network Configuration
Machine
computer
Coplan computer
Private network between
machine computer and Coplan
computer
SIPLACE LAN
SIPLACE Pro
Figure 4-1: Network connections between the machine and SIPLACE Pro
In two-computer operation a separate private network is set up between the machine computer and
the Coplan computer via a subnet mask.
Fixed IP addresses for the machine computer and the Coplan computer can thus be assigned for
all SIPLACE machines. These IP addresses are not known outside the private network, for
instance in the SIPLACE LAN.
These IP addresses need not be further configured by the operator while the station software is
being installed.
