TRANSPORTATION - MAJOR RELOCATION
MACHINE SUPPLIES AND ENVIRONMENTAL CONDITIONS
Chapter Issue 2, Jul 16 Technical Reference Manual 43.43
Figure 43-13 Style 4 Covers (Back to Back option)
TRANSPORTATION - MAJOR RELOCATION
MACHINE SUPPLIES AND ENVIRONMENTAL CONDITIONS
43.44 Technical Reference Manual Chapter Issue 2, Jul 16
Figure 43-14 Style 5 Covers
219
1342
Front of Board
499
1624
R455
Max dimension from
pivot point
Plan View
1106
(1357 min to 1497 max.)
1477
104
Front View
1150
Transfer Height 960
(840 min to 980 max)
Side View (Right)
Weight
Boxed - 8 kg, Unboxed - 6 kg10 54
(Dependent upon configured options
selected with the machine)
Note
All dimensions
in millimetres
Board transfer
height 8
- 980 mm40
Screen load height 925 - 1
065 mm
(1929 min to 2069 max.)
2049
(1352 min to 1492 max.)
1472
TRANSPORTATION - MAJOR RELOCATION
MACHINE SUPPLIES AND ENVIRONMENTAL CONDITIONS
Chapter Issue 2, Jul 16 Technical Reference Manual 43.45
Centre of Gravity and Seismic Anchorage
Figure 43-15 Style 1 Covers (Only)
Side View (right)
CG
L2
a
b
h
L1
Front View
CG
L3
d
b
h
c
Centre of Gravity
a
b
c
d
h
L1
L2
L3
1150mm
130mm
1106mm
530mm
485mm
565mm
665mm
541mm
Plan View
Centre of Gravity
Seismic Anchorage
Machine Feet
(in 4 positions)
Min = -100kg
Max =
+400kg
Min = -100kg
Max =
+400kg
Min = -100kg
Max =
+400kg
Min = -100kg
Max =
+400kg
Seismic Anchorage
The calculations for the downward and upward force of the feet
is calculated in line with the 1997 Uniform Building Code and
SEMI S2-0703. Results indicate that under worse circumstances
(calculation for hazardous fluids) an upward lifting force has to be
expected and it is strongly recommended to secure the machine
directly to the floor.
NOTE
In the figure on the left, negative
numbers
are upward loads and
positive
numbers
are downward
loads.
Appropriate attachment points may be fitted to the front and rear
of the machine base frame. For more information, contact DEK
Printing Machines.
Alternatively, the supplied machine feet can be replaced with feet
incorporating holes allowing the feet to be secured directly to the floor.
Additional seismic calculations must be undertaken for the floor and
any anchor points that are used.
The length of the machine feet (measurement in the figures above)b
must not exceed 130mm to meet seismic anchorage calculations.
