44 0712-001 (3) Detachthevacuumlterfromthecap. Note Do not throw away the cap. V acuum Filter Cap Fig. 21 (4) Attachanewvacuumltertothecap. (5) Engagethevacuumlterreplacementjigwiththehookof…

430712-001

12. Replacement Procedure of Vacuum Filter

(1) Engagethevacuumlterreplacementjigwiththehookofthecap.

Placement Head

Vacuum Filter Replacement Jig

Cap

Fig. 18

Fig. 19

(2) Bringthevacuumlterreplacementjigstraightdownandpulloutthe

cap from the placement head.

Note

 Thevacuumlterreplacementjigshouldnotcomeofffromthecap.

Placement Head

Vacuum Filter

Fig. 20

440712-001

(3) Detachthevacuumlterfromthecap.

Note

Do not throw away the cap.

Vacuum Filter

Cap

Fig. 21

(4) Attachanewvacuumltertothecap.

(5) Engagethevacuumlterreplacementjigwiththehookofthecapand

push the cap straight into the placement head in the reverse order of cap

detachment.

Note

Push the cap into the placement head as far as possible.

(6) Follow the reverse procedure of the jig engagement (engagement

procedureforvacuumlterreplacementjig)toslideitouthorizontally

from the hook of the cap.

12. Replacement Procedure of Vacuum Filter

450712-001

13. List of Consumables

Listed below are the parts that may be consumed within one year.

Consult our marketing department or sales agency whenever you need to

purchase these parts.

Table 7

Product Name Part No. Part Name Q'ty

Recommended

Q'ty/Year

Note (a)

Exploded

View

Remarks

Vacuum Filter 630 069 5816 AIR LIN EQPT 3 18 Fig. MT-3

Note

(a) The numbers entitled "Recommended Q'ty/Year" indicate the

referential values.

(b) Refer to "11. Maintenance Spots" for the detailed information on how

to replace the parts with new ones.
