LA 404-2 Pattern Control System
3
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
User Qualifications
Equipment owners are responsible for ensuring that users:
receive safety training appropriate to their job function as directed by
governing regulations and best industry practices
are familiar with the equipment owner’s safety and accident
prevention policies and procedures
receive, equipment- and task-specific training from another qualified
individual
NOTE: Nordson can provide equipment-specific installation,
operation, and maintenance training. Contact your Nordson
representative for information
possess industry- and trade-specific skills and a level of experience
appropriate to their job function
are physically capable of performing their job function and are not
under the influence of any substance that degrades their mental
capacity or physical capabilities
Applicable Industry Safety Practices
The following safety practices apply to the use of the equipment in the
manner described in this document. The information provided here is not
meant to include all possible safety practices, but represents the best safety
practices for equipment of similar hazard potential used in similar industries.
Intended Use of the Equipment
Use the equipment only for the purposes described and within the limits
specified in this document.
Do not modify the equipment.
Do not use incompatible materials or unapproved auxiliary devices.
Contact your Nordson representative if you have any questions on
material compatibility or the use of non-standard auxiliary devices.
Instructions and Safety Messages
Read and follow the instructions provided in this document and other
referenced documents.
Familiarize yourself with the location and meaning of the safety warning
labels and tags affixed to the equipment. Refer to Safety Labels and
Tags at the end of this section.
If you are unsure of how to use the equipment, contact your Nordson
representative for assistance.
LA 404-2 Pattern Control System
4
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
Installation Practices
Install the equipment in accordance with the instructions provided in this
document and in the documentation provided with auxiliary devices.
Ensure that the equipment is rated for the environment in which it will be
used and that the processing characteristics of the material will not
create a hazardous environment. Refer to the Material Safety Data
Sheet (MSDS) for the material.
If the required installation configuration does not match the installation
instructions, contact your Nordson representative for assistance.
Position the equipment for safe operation. Observe the requirements for
clearance between the equipment and other objects.
Install lockable power disconnects to isolate the equipment and all
independently powered auxiliary devices from their power sources.
Properly ground all equipment. Contact your local building code
enforcement agency for specific requirements.
Ensure that fuses of the correct type and rating are installed in fused
equipment.
Contact the authority having jurisdiction to determine the requirement for
installation permits or inspections.
Operating Practices
Familiarize yourself with the location and operation of all safety devices
and indicators.
Confirm that the equipment, including all safety devices (guards,
interlocks, etc.), is in good working order and that the required
environmental conditions exist.
Use the personal protective equipment (PPE) specified for each task.
Refer to Equipment Safety Information or the material manufacturer’s
instructions and MSDS for PPE requirements.
Do not use equipment that is malfunctioning or shows signs of a
potential malfunction.
LA 404-2 Pattern Control System
5
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
Maintenance and Repair Practices
Perform scheduled maintenance activities at the intervals described in
this document.
Relieve system hydraulic and pneumatic pressure before servicing the
equipment.
De-energize the equipment and all auxiliary devices before servicing the
equipment.
Use only new factory-authorized refurbished or replacement parts.
Read and comply with the manufacturer’s instructions and the MSDS
supplied with equipment cleaning compounds.
NOTE: MSDSs for cleaning compounds that are sold by Nordson are
available at www.nordson.com or by calling your Nordson
representative.
Confirm the correct operation of all safety devices before placing the
equipment back into operation.
Dispose of waste cleaning compounds and residual process materials
according to governing regulations. Refer to the applicable MSDS or
contact the authority having jurisdiction for information.
Keep equipment safety warning labels clean. Replace worn or damaged
labels.
Equipment Safety Information
This equipment safety information is applicable to the following types of
Nordson equipment:
hot melt and cold adhesive application equipment and all related
accessories
pattern controllers, timers, detection and verification systems, and all
other optional process control devices
Equipment Shutdown
To safely complete many of the procedures described in this document, the
equipment must first be shut down. The level of shut down required varies
by the type of equipment in use and the procedure being completed.
If required, shut down instructions are specified at the start of the
procedure. The levels of shut down are:
Relieving System Hydraulic Pressure
Completely relieve system hydraulic pressure before breaking any hydraulic
connection or seal. Refer to the melter-specific product manual for
instructions on relieving system hydraulic pressure.
