Programs (1 - 100)
This setup menu screen can be used to save and recall any of the 100
programs, as well as copy one channel to another.
NOTE: The user can only call up programs. The other two options are not
available to users.
Program 01
Save as 01 No
Recall 01 No
Copy CH# to CH# No
O681
1. To save a program
a. Press the or button for the cursor to appear beside the
program number of Save as.
b. Press the or button to select the desired program from
01 - 100.
c. Press the or button for the cursor to appear beside No.
d. Press the or button to change from N to Y, and this will save or
recall the desired program.
2. To recall a program
a. Press the or button for the cursor to appear beside the
program number of Recall.
b. Press the or button to select the desired program from
01 - 100.
c. Press the or button for the cursor to appear beside No.
d. Press the or button to change from N to Y, and this will save
or recall the desired program.
3. To copy a channel to another channel:
a. Press the CHANNEL SELECT button on the front panel of the
pattern controller to select a channel number (Copy CH1 - 4) whose
settings you would like to copy to another channel number.
b. Press the or button for the cursor to appear beside CH1.
c. Press the or button to go from CH2 - CH4.
d. Press the or button for the cursor to appear beside No.
e. Press the or button to change N to Y and this will copy the
channel settings.
NOTE: The copy CH# to CH# feature copies the channel data and setup
parameters (like delay, duration, bead type and trigger assignment) from the
source channel to the destination channel.
LA 404-2 Pattern Control System
49
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
Warnings
The pattern controller monitors warning conditions like:
Trigger 1 - 4 too short (clipping), T1- 4 max distance exceeded (jamming),
Ch1 - 4 short circuit, etc.
NOTE: Warnings appear in the display. They remain visible until they are
acknowledged by pressing any button.
The pins A, B and C at the remote output (refer to Page 22) are wired as an
alarm output. The alarm output can be used for a machine stop signal or to
trigger a remote device.
When a fault occurs, there are two cases in which the alarm output is
activated. In all other cases, only a warning appears in the display.
1. Short circuit of the gun output
2. The jam detector signals a fault
Warnings
O682
Fault Condition
A fault condition occurs typically when there is a hardware or software
defect. When a fault condition occurs, the user will need to take immediate
action.
Warning Condition
A warning condition alerts the user that there may be an error with the
setup of the pattern controller. When a warning condition occurs, immediate
action may not be required.
LA 404-2 Pattern Control System
50
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
Encoder Scaling
This menu is used to display the encoder type and configure the encoder
scaling. The pattern controller automatically detects the type of encoder
installed. If no encoder is detected, the Not connected message appears in
the display.
The encoder scaling ratio is determined by entering the number of pulses
per millimeter that the encoder outputs when installed. If a quadrature
encoder is used, the direction of rotation travel maybe reversed.
Encoder Scaling
Encoder Single
Custom 1,000 ppmm
Direction Forward
O683
1. To set the encoder scaling
a. Press the or button for the cursor to appear beside Custom.
b. Press the or button to set the encoder gearing ratio from
0.1 - 20,000 ppmm (pulses per millimeter).
2. To set the encoder direction
Press the or button to set Direction to Forward or Backward.
NOTE: The direction parameter is used only if a quadrature encoder is
detected.
