LA 404-2 Pattern Control System
12
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
System Features
Self configuration upon power up
LCD programming/setup menu screen
The operating system software in the pattern controller allows
electronic field software upgrades via the computer’s serial port
Capable of storing up to 100 programs
Can dynamically change program parameters during pattern
controller operation
Monitors fault and warning conditions
Guns dispense a maximum of four beads. Possible bead types:
normal, continuous, autospot, dot, random bead and random dot.
Four channels with up to two gun capacity per channel
Each channel has a corresponding driver capable of driving two
guns simultaneously
Automatically converts glue line patterns to other bead types
Digital display of machine speed, work rate, and total count
Programmable gun compensation
Signals the active channel for the selected program at the remote
output.
Pressure run-up
Remote gun purge
Encoder scaling
Signals a drop below the minimum speed at the remote output.
Integrated tip sealer control
32 V
DC
gun driver
Software Upgrade
The pattern controller’s software can be upgraded, and the user programs
can be saved or restored in the field by using the Nordson Configuration
Manager (NCM). The NCM is a Windows -based application that allows the
pattern controller to communicate with a personal computer (PC). The
communication is enabled by a serial cable that is connected to the COM
port (selected during the software installation routine) and the serial port
connection (COM port) located on your pattern controller’s rear panel.
The NCM can be obtained from:
www.enordson.com/support
LA 404-2 Pattern Control System
13
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
Specifications
Operating Conditions
Item Specification
Ambient temperature
range
0 − 40 C (32 − 104 F)
Enclosure rating IP40
Humidity 5 % − 95 % (non−condensing)
Altitude -20 − 5000 feet above sea level
Physical Data
Item Specification
Dimensions (WxDxH) 310 mm x 270 mm x 205 mm (12.2 in. x 10.6
in. X 8.0 in.)
Power supply
Item Specification
Input voltage 85 − 240 V
AC
, 50/60 Hz
Replacement fuse 5 x 20 mm, 250 V
AC
, 3.15 A
LA 404-2 Pattern Control System
14
P/N 7119995A
2006 Nordson Corporation
LA 404-2
Issued 12/06
Performance
Item Specification
Maximum operational
line speed
600 m/min, 1 p/mm encoder gearing
Maximum pulse fre-
quency
100 kHz
Encoder resolution 0.1 p/mm − 20 p/mm
Bead resolution 1.0 mm
Adhesive placement ac-
curacy
1.0 mm under the following conditions:
a. Encoder resolution at least 1 p/mm
b. Acceleration levels +2.0 m/s
2
and -2.0
m/s
2
(0 − maximum line speed)
c. Gun compensation (on/off) 5.0 ms or less
d. All triggers activated simultaneously
Gun compensation
range
0 - 500 mm in steps of 0.1 mm at a pre-
scribed speed
Trigger setup time Processes all trigger inputs and generates the
initial gun output within 1 ms
Line speed sensor input
(encoder or MSD)
One encoder input that accepts single and
quadrature type encoders
Number of channel and
gun output
Four programmable channel (or gun) outputs
Maximum number of
beads per channel
Four beads per programmed channel
Maximum pattern seg-
ment length
32768 encoder pulses
Minimum bead delay
(gap)
0 mm
Maximum bead duration Equal to the maximum pattern segment length
Minimum programmable
gun-to-trigger offset
(GTO)
2 mm
Maximum gun-to-trigger
offset (GTO)
Equal to maximum pattern segment length
minus the first bead offset
Digital circuitry I/O
insulation
All remote inputs and outputs are electrically
insulated from the internal digital circuits
