Page HANWHA TECHWIN 1 SLM110S Contents Mechanical Part SO Optics Camera Ass'y ... .............................................. ............. 4 Feeder Base Ass'y ............ ................................ .…
Page
HANWHA TECHWIN
1
SLM110S
Contents
Mechanical Part
SO Optics Camera Ass'y.............................................................. 4
Feeder Base Ass'y ....................................................................... 6
Conveyor Ass’y............................................................................. 8
FLASH Conveyor Ass’y .............................................................. 22
FLASH Backup Block Ass’y........................................................ 34
Backup Table Ass’y .................................................................... 36
Base Frame Ass’y ...................................................................... 38
Base Module Ass’y ..................................................................... 40
Head Ass’y ................................................................................. 42
Air Ass’y...................................................................................... 75
Moving Frame Ass’y ................................................................... 82
Fixed ANC Ass’y......................................................................... 88
Cover Ass’y ................................................................................ 90
Control Rack Ass’y ..................................................................... 96
Electric Panel Ass’y .................................................................. 100
Electric Device Ass’y ................................................................ 104
Electric Control Part
Harness Wiring Diagram .......................................................... 109
Feeder Board Interface ............................................................ 110
Conveyor Board Interface ........................................................ 118
Axis Sensor Board Interface..................................................... 128
AXIO Board Interface .............................................................. 132
Head IF Board Interface ........................................................... 140
Motor IF Board Interface .......................................................... 144
Safety Interlock Interface.......................................................... 152
Electric Circuit Diagram............................................................ 156
Articles of Consumption
Articles of Consumption .......................................................... 167
Page
HANWHA TECHWIN
2
SLM110S
Mechanical Part
