25
Component Feeding
Component Changeover Table
SIPLACE X component
changeover table
The SIPLACE X component
changeover tables are stand-
alone and easily maneuver-
able modules that are moved
into the machine with the
automatic docking unit. This
ensures that the table is
accurately positioned in the
placement machine. Reels
are kept in the tape container
on the component change-
over table.
A cutting device on the
machine automatically cuts
the used tape. The compo-
nent changeover tables can
be set up directly on the
machine or in an external
set-up area with feeder mod-
ules. The benefits of offline
set-up are that the set-ups
can be prepared without
stopping the line. This allows
the set-up to be changed
very quickly using the
changeover table principle.
The SIPLACE X component
changeover table also sup-
port extremely high-speed
attachment and removal of
the feeder modules while the
placement process is run-
ning. The component feed-
ers are at rest during the
placement process - allowing
tapes to be spliced without
stopping the machine.
If an optional component bar-
code reader and the Setup
Center option are installed, it
is possible to read and check
the barcodes on the tape
reels. This makes sure that
the component is allocated to
the right track, and the PCB
placement can be traced
using traceability software.
Dummy feeder modules are
used at unassigned locations
to protect the operators.
SIPLACE HF component
changeover table
The SIPLACE HF compo-
nent changeover table can
also be used on SIPLACE
X2, X3 and X4 machines,
which means that all S tape
feeder modules and all other
feeder modules from this
generation can still be used.
This ensures maximum pro-
tection for your investment.
You must make sure, how-
ever, that the appropriate
docking unit is fitted for com-
ponent changeover tables
from the SIPLACE HF series.
The SIPLACE HF series
component changeover table
also cannot be used with the
20-nozzle Collect&Place
head.
Communication unit
Waste container
for remaining empty tape
Component
table
Tape container
SIPLACE X
component changeover table
SIPLACE HF
component changeover table
Waste container
for remaining empty tape
Component
table
Tape container
26
Component Feeding
Component Changeover Table
Technical Data
SIPLACE X component
changeover table (COT)
SIPLACE HF component
changeover table (COT)
a
a) The SIPLACE HF component changeover table and feeder modules cannot be used together with the
20-nozzle Collect&Place head.
Length x width 752 x 592 mm²
Height for
830 mm PCB transport height
900 mm PCB transport height
930 mm PCB transport height
950 mm PCB transport height
820 mm
890 mm
920 mm
940 mm
830 mm
900 mm
930 mm
950 mm
Weight
without feeder modules
with feeder module at
all locations
80.4 kg
139.6 kg
88.9 kg
143.7 kg
Reel diameter
standard
maximum
up to 432 mm (17")
483 mm (19")
up to 432 mm (17")
483 mm (19")
Locations for feeder modules max. 40 (8 mm X) max. 15 (3 x 8 mm S)
Changeover time < 1 minute < 1 minute
Component Feeding
(SIPLACE X component change-
over table)
4 COTs with tape reel holders and integral waste containers
40 x 8 mm feeder module locations per COT or matrix tray
changer in COTs at locations 2 and 4
Feeder module types
(SIPLACE X)
Component tapes, waffle-pack trays, stick magazines and label
feeders with adapter
Feeding capacity
(SIPLACE X component
changeover table)
160 8 mm X feeder modules
80 12 mm X feeder modules
52 16 mm X feeder modules
52 24 mm X feeder modules
40 32 mm X feeder modules
32 44 mm X feeder modules
24 56 mm X feeder modules
20 72 mm X feeder modules
16 88 mm X feeder modules
Component feeding
(HF component
changeover table
a
)
4 COTs with tape reel holders and integral waste containers
15 slots, 30 mm wide per COT
matrix tray changer rather than a COT at locations 2 and 4
Feeder module types
(SIPLACE HF
a
)
Component tapes, bulk cases, stick magazines, Dip module, waf-
fle-pack trays, OEM feeder modules (surf tape, component dis-
posal module, waffle-pack trays, Jedec trays, label feeder
modules, inline programming feeder modules)
Feeding capacity
(SIPLACE HF component
changeover table
a
)
60 tape feeder modules 3 x 8 mm S (180 tracks)
60 tape feeder modules 2 x 8 mm S (120 tracks)
60 tape feeder modules 12/16 mm S
40 tape feeder modules 24/32 mm S
28 tape feeder modules 44 mm S
24 tape feeder modules 56 mm S
20 tape feeder modules 72 mm S
16 tape feeder modules 88 mm S
27
Component Feeding
X Tape Feeder Modules
SIPLACE X tape feeder
modules are intelligent tape
feeder modules for flexible
production environments.
They greatly simplify set-up
and conversion tasks. All
SIPLACE X feeder modules
support tape splicing as stan-
dard, which prevents
machine stoppages when
refilling.
The benefits at a glance:
Conversion-friendly
• All SIPLACE X tape feeder
modules are designed as
single-track feeder mod-
ules. This minimizes any
restrictions during conver-
sion.
• Conversion is fast and
straightforward, and can
even be done during a
production run.
• Omega profiles on both
the tape feeder module
and the table allow the
tape feeder modules to be
attached and removed
while production is run-
ning.
Operator-friendly
• Contactless data and
power transmission make
it easier to attach/remove
the tape feeder modules
• Menu-driven LCD display
with full graphics capabil-
ity supports the operator
with the latest information
• A multicolor status dis-
play signals the operating
statuses of the X tape
feeder module:
- Green: “Standby/Set-up
in progress”
- Orange: “Component
running out”
- Red: “Fault”
- LED off: “Tape feeder
module is not in current
set-up and may be
removed”
Robust
• Brushless motors extend
the service life of the X
tape feeder modules.
Intelligent
• A unique tape feeder mod-
ule ID ensures that the
component is assigned
exactly to the tape feeder
module. This makes reli-
able set-up verification
very simple.
• Component pitch, feeding
speed and other functions
are set automatically
when you download the
set-up program.
High feeding accuracy
• Closed-loop control dis-
tance measurement guar-
antees highly accurate
component feeding, even
with 01005 components.
a) PSA Kit available as an option.
b) 01005-compliant.
c) In 4mm increments.
d) PSA Kit, standard.
Technical data
Tape feeder
module
Width
[mm]
Loca-
tion
Transport incre-
ment [mm]
Max. tape
height [mm]
8 mm X
a,b
10.8 1 1/2/4/8 3.5
12 mm X
a
22.6 2 4 - 16
c
6.5
16 mm X
d
34.4 3 4 - 20
c
25
24 mm X
d
34.4 3 4 - 32
c
25
32 mm X
d
46.2 4 4 - 40
c
25
44 mm X
d
58.0 5 4 - 52
c
25
56 mm X
d
69.8 6 4 - 64
c
25
72 mm X
d
81.6 7 4 - 80
c
25
88 mm X
d
105.2 9 4 - 96
c
25
Tape reels 178 to 483 mm in diameter (7" - 19")
Changeover time 8 s
