SIPLACE Services

Training Courses for the SIPLACE X-Series

Capability Transfer

Under the heading of Capa-

bility Transfer we offer solu-

tions that will enable your

team to carry out tasks such

as verifying placement accu-

racy or the serviceability of

SIPLACE feeder modules to

SIPLACE standards. Not

only will we provide you with

all the tools or testing sys-

tems you will need for the

desired period, but we will

also train and coach your

team, even on site on your

premises. We will certify your

team and provide certificates

stating that its work conforms

to the SIPLACE standards.

We provide the Capability

Transfer solutions in the form

of standard packages. You

decide when you want the

solution and how often.

SMT Academy

The SMT Academy provides

training courses to give your

team the necessary technical

skills - from basic SIPLACE

operator training through to

advanced courses for your

experts. We can run courses

on your site or in one of our

SIPLACE Training Centers

around the world. In addition

to our range of standardized

courses, we can also tailor

training programs to your

specific needs. Before we do

that, we recommend that we

first carry out a knowledge

gap analysis as this will

enable us to identify very

easily where you have a

need to refresh technical

knowledge and skills.

SIPLACE training units are

always modular. This means

that you can register for a

standard course, but we can

also put together individual

topics to create a special

course specifically for your

production situation.

We can also provide upgrade

training that covers just the

differences between the

machines that you already

have in use and the newly-

installed machine platform.

If necessary we can also

modify the content of

courses to cover your spe-

cific requirements.

All of our courses take

account of the roles and

responsibilities of the partici-

pants, and can be run either

at a SIPLACE Training Cen-

ter or at your own production

facility.

The courses are also offered

in a wide range of languages.

Please ask for further details.

Options, Tools and Spares

Under Options, Tools and

Spares we offer machine

accessories and options

(some of which are listed in

this document), a range of

tools that you can use to

check or adjust your equip-

ment and original SIPLACE

spare parts to ensure top

quality repairs.

Training Courses Especially for the SIPLACE X-Series

Special operator training, maintenance training and technical train-

ing (setting up and repairing systems) courses are available for the

SIPLACE X-series.

Standard Training Courses for

the SIPLACE X-Series

• SIPLACE Training for Operators

• SIPLACE Minor and Major Main-

tenance Training for the X-

Series

• SIPLACE Technical Training for

the X-Series

Advanced Courses and Cus-

tomer-specific Training for the

SIPLACE X-Series

• SIPLACE X-Series

Advanced Training Module

• SIPLACE X-Series

Upgrade Training Module

Reference to other training

courses

• SIPLACE Programmer Training

for SIPLACE Pro

• SIPLACE Vision Training

• SIPLACE Feeder Care Training

Maximum Quality in Production

Maximum quality in pro-

duction

The SIPLACE X-series not

only provides market-leading

machine quality; it also guar-

antees maximum product

quality through a combina-

tion of the following features:

100% placement process

control

The SIPLACE X-series has

various control mechanisms

as standard that guarantee

maximum placement reliabil-

ity. For example, sensors

check whether the compo-

nent was picked up or set

down correctly. Force sen-

sors also check the specified

component set-down forces

and compensate for differ-

ences in height during pick-

up and any bumps on the

PCB during placement.

Digital vision inspection

The digital vision system

guarantees extremely fast

and reliable component rec-

ognition, while being very

simple to use. The system

identifies each individual

component from its shape

and color. Using different illu-

mination and brightness lev-

els, almost every package

form can be easily detected.

The system also stores

images of the components,

known as “vision dumps”.

These show which compo-

nents were rejected. As a

result, errors can be detected

earlier when introducing new

products, thus increasing

process reliability. The vision

dumps also provide good

negotiation tools if defective

components are supplied.

Intelligent software for set-

up verification

The SIPLACE X series set-

ups are verified on the PCB,

on the component roll and by

the intelligent SIPLACE X

feeder modules with refer-

ence to the barcode. This

helps to avoid set-up errors.

This network of tests consid-

erably lowers dpm rates and

increases the first pass yield.

Quality values for the SIPLACE X-series

Pickup rate 99.95%

a) Based on average values from evaluations.

Dpm rate  3 dpm

Technical Data

SMEMA Interface

Connector Assignment

Signal interface (14-pole connecting socket, interface standard 1.2)

Upstream station X1 Downstream station X2

Pin 1 NOT READY + Pin 1 NOT READY +

Pin 2 NOT READY – Pin 2 NOT READY –

Pin 3 BOARD AVAILABLE + Pin 3 BOARD AVAILABLE +

Pin 4 BOARD AVAILABLE – Pin 4 BOARD AVAILABLE –

Pin 5 Not used Pin 5 Not used

Pin 6 Not used Pin 6 Not used

Pin 7 Not used Pin 7 Not used

Pin 8 Reserved Pin 8 Reserved

Pin 9 Reserved Pin 9 Reserved

Pin 10 Reserved Pin 10 Reserved

Pin 11 Reserved Pin 11 Reserved

Pin 12 Reserved Pin 12 Reserved

Pin 13 Reserved Pin 13 Reserved

Pin 14 Reserved Pin 14 Reserved
