Component Feeding

Matrix Tray Changer (MTC)

For numerous tray fed com-

ponents we recommend an

automatic tray change using

a matrix tray changer (MTC).

The MTC set-up is precisely

matched to the placement

sequence in order to opti-

mize the timings and dis-

tances traveled.

Two bins with component

trays move independently of

one another in the vertical

direction until the desired

magazine is within the range

of the feed axis. The horizon-

tal feed axis transports the

waffle-pack tray from the bin

into the access area of the

placement head.

The first magazine is made

available as soon as a PCB

moves onto the PCB con-

veyor, and valid panel and

set-up data is available. All

other magazine changes are

carried out time-neutrally

during the placement pro-

cess. The magazines can be

refilled without stopping the

machine. Defective compo-

nents are returned to the

original tray.

The matrix tray changer can-

not be used with the 20-

nozzle Collect& Place head.

Tray supply 1

Feed

axis 1

Positioning options for the MTC:

locations 2 and 4

Tray supply 2

Feed

axis 2

Component Feeding

Matrix Tray Changer (MTC)

Technical Data

Electrical ratings

Tray supply 1 (XL) Tray supply 2

Dimensions

Length x width

Height

1305 x 600 mm²

1490 mm for 830 mm PCB transport height

1560 mm for 900 mm PCB transport height

1590 mm for 930 mm PCB transport height

1640 mm for 950 mm PCB transport height

Weight (basic equipment) approx. 500 kg (with PCB magazines and

waffle-pack tray carriers)

Weight (fully equipped) approx. 534 kg (with components)

Weight (moving mass) approx. 80 kg approx. 43.5 kg

Cassette size (L x W x H) 391.2 x 305.6 x 93.3 mm³ 352.7 x 154.8 x 133.8 mm³

Cassette weight

(fully equipped)

(without waffle-pack tray carrier)

approx. 11 kg

approx. 1.7 kg

approx. 7.5 kg

approx. 1.35 kg

Weight of the

waffle-pack tray carrier

850 g 150 g

Dimensions of the waffle-pack tray

carrier (L x W x H)

386.5 x 295.8 x 11.1 mm³ 371 x 146 x 10.1 mm³

Distance from cassette to cassette 96 mm 135 mm

Distance from level to level 12 mm 11.8 mm

Storage capacity 30 XL waffle-pack tray carriers

with 60 JEDEC or

30 special magazines of max-

imum size

40 waffle-pack tray carriers

with 40 JEDEC

waffle-pack trays

Changeover time (over 5 levels) approx. 2 s approx. 1.5 s

Max. height of component and waf-

fle-pack tray, including tolerances

all levels filled

one level free

two levels free

8.5 mm

19.5 mm

31.5 mm

8.5 mm

19.5 mm

–

Supply voltage 3 x 400 VAC, 50 Hz (Europe)

3 x 208 VAC, 60 Hz (U.S.A.)

Total power 1.5 kW

Apparent power 3.85 kVA

Rated current 2.7 A at 3 x 400 VAC

4.2 A at 3 x 208 VAC

Fuses 3 x 16 A

Rated power consumption of the largest consumer 2 A

Component Feeding

Waffle-Pack Changer (WPC)

The waffle-pack changer

makes the Flatpack IC avail-

able in the waffle-pack trays

to avoid unnecessary loss of

time during storage and

automatic changing of the

waffle-pack trays. Program-

mable, random access to up

to 28 waffle-pack trays also

considerably increases the

range of components that

can be made available. The

waffle-pack changer has an

integral chassis, and is easy

to move to other locations.

It is supplied with the PCB

conveyor height imple-

mented for the machines, but

can also be adapted for the

830, 900, 930 and 950 mm

PCB conveyor heights with

just a few simple operations.

There are 4.5 locations for

30 mm width S feeder mod-

ules available on the compo-

nent table.

Location options

for the WPC:

SIPLACE X3: feeder location 2

SIPLACE X2: feeder locations 2 + 4
