KE2040Instruction Manual Ver2.01,REV04.2003.6.25.pdf - 第183页
4 – 73 • Alum inum electr olytic capacitor • SOT (horizontal) Dimens ions (hori zontal) Dimens ions (V ert ical) Component height Lead length
4 – 72
4.7.2.2 Examples of component dimensions
See the following figures to create data.
The dimensions and shape of each type of component are shown below.
• Square chip
• MELF
Dimensions (horizontal)
Dimensions
(Vertical)
Component height
Dimensions (horizontal)
Dimensions
(Vertical)
Component height
4 – 73
• Aluminum electrolytic capacitor
• SOT
(horizontal)
Dimensions (horizontal)
Dimensions
(Vertical)
Component height
Lead length
4 – 74
• SOP
• SOP (with a heat sink)
• SOJ
(horizontal)
(horizontal)
(horizontal)
