5 − 8
5.2.1 Setting range
5.2.1.1 Lead components
(1) QFP, PQFP, PLCC (QFJ) and IC socket
Components having fine-pitch lead on four sides
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
QFP, PQFP 0.30 mm (Note 1) 1.27 mm
QFJ (PLCC) 1.27 mm 1.27 mm
1 Pitch (lead pitch)
IC socket 1.00 mm 1.27 mm
None
2
Len (lead length) 0.30 mm 3.00 mm None
3
Bot., R, Top, L (number of leads on each side) 7 (Notes 3 and 4) 128 None
4
Bend (Bent lead detecting level) 15% 20% 25% 30% None (No check) 20%
5
Missing Start/No (First missing lead/Number of
missing leads)
Up to three blocks of missing leads
can be set.
0
(2) SOP and TSOP
Components having fine-pitch leads on two sides (three sides also)
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Pitch (lead pitch)
0.30 mm (Notes
1 and 3)
1.27 mm None
2
Len (lead length) 0.30 mm 3.00 mm None
3
Bot., R, Top, L (number of leads on each side) 7 (Note 3) 128 None
4
Bend (Bent lead detecting level) 15% 20% 25% 30% None (No check) 20%
5
Missing Start/No (First missing lead/Number of
missing leads)
Up to three blocks of missing leads
can be set.
0
(3) Unidirectional lead connector/Bidirectional lead connector/Z lead connector
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Pitch (lead pitch) 0.30 mm (Note 1) 2.54 mm None
2
Len (lead length) 0.30 mm 3.00 mm None
3
Bot., R, Top, L (number of leads on each side) 2 (Notes 2, 3 and 5) 128 None
4
Bend (Bent lead detecting level) 15% 20% 25% 30% None (No check) 20%
5
Missing Start/No
(First missing lead/Number of missing leads)
Up to three blocks of missing leads
can be set.
0
6 View Field (Range of leads to be recognized)
Select one of the settings: “All”,
“Only the both ends lead”, and “Both
ends lead exclusion”.
All
7
L Top, R Top, L Bot., and R Bot.
(Upper left, upper right, lower left and lower right)
When you select “Only the both ends
lead” or “Both ends lead exclusion” at
the “View Fi eld” setting item, set the
number of leads here.
None
As shown in Section 5.6,
⑰
“Z lead connector” on the previous page, leads
located on the bottom side of a Z lead connector are supposed to be shifted
toward the right side by half pitch (when viewed from the top). If leads on the
top side are shifted toward the right side, specify one missing lead on the top
left side and bottom right side respectively.
5 − 9
(4) SOJ
Components having J leads on two sides
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Pitch (lead pitch) 1.27 mm 1.27 mm None
2
Len (lead length) 0.30 mm 3.00 mm None
3
Bot., R, Top, L (number of leads on each side) 7 (Note 4) 128 None
4
Bend (Bent lead detecting level) 15% 20% 25% 30% None (No check) 20%
5
Missing Start/No
(First missing lead/Number of missing leads)
Up to three blocks of missing leads
can be set.
0
(5) Aluminum electrolytic capacitor (See Note 6.)
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Len (lead length) 1.50 mm 15.00 mm None
2
Wd (lead width) 0.50 mm 1.50 mm None
(6) GaAsFET (See Note 6.)
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Len Bot, R
(length of a lead on the bottom and right sides)
1.00 mm 15.00 mm None
2
Wd Bot, R
(width of a lead on the bottom and right sides)
0.50 mm 1.50 mm None
(7) SOP (equipped with a heat sink)
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Pitch (lead pitch) 0.4 mm 1.27 mm None
2
Len (lead length) 0.30 mm 3.00 mm None
3
Bot., R, Top, L (number of leads on each side) 7 128 None
4
Bend (Bent lead detecting level) 15% 20% 25% 30% None (No check) 20%
5
Missing Start/No
(First missing lead/Number of missing leads)
Up to three blocks of missing leads
can be set. (Note 7)
0
Note 1: The lead pitch less than 0.4 mm is optional. When the lead pitch is less than 0.4 mm, the
dimensions of a component should be 24 mm x 24 mm or less (for a 27-mm VCS).
Note 2: The recognition precision of a component whose number of leads is less than four cannot be
guaranteed.
Note 3: When image of a component is divided into two for recognition, the minimum number of
leads is 14. When it is divided into three, the minimum number of leads is 21.
Note 4: The machine cannot recognize divided images of a PLCC (GFJ) or SOJ component for
recognition.
Note 5: Only the standard VCS can divide and recognize image of a connector.
Note 6: The machine cannot recognize divided images of an aluminum electrolytic capacitor. Only
the standard VCS can recognize this type of component.
Note 7: For this component, enter the number of missing leads on a heat sink.
5 − 10
5.2.1.2 Ball components
(1) BGA
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Pitch (lead pitch) 1.00 mm 3.00 mm None
2
Wd (lead width) 0.40 mm 1.00 mm None
3
Bot., R, Top, L (number of
leads on each side)
4 51 (Note 1) None
4
Missing Start/No (First
missing lead/Number of
missing leads)
Up to three blocks of missing leads can be set. 0
5
Contrast
Select one of the settings: “PWB”, “Ceramic”, “All balls” and
“All land”. (Notes 2 and 3)
All balls
6
Base Style
Select one of the settings: “Standard”, “Index mark 4
corner”, “Index mark 3 corner”, “Index mark 2 corner”, “Index
mark 1 corner”, “Outer belt type mark” and “Mark overspill
type”.
Standard
7
Ball Pattern
Select one of the settings: “Browse”, “Edit”, “Standard
BGA”, “Peripheral BGA”, “Staggered std. BGA (More out)”,
“Staggered per. BGA (More out)”, “Staggered std. BGA
(Fewer out)” and “Staggered per. BGA (Fewer out)” (*).
None
8
NumLn
For a peripheral ball pattern, set the number of lines on which
balls are located with being viewed from the outside.
None
9
Diameter/Level
Select “Yes” or “No” to check the diameter of a ball and set
the level for checking the diameter (1 to 100 %)
No (50%)
10
Variant/Level
Select “Yes” or “No” to check deformation of a ball and set
the level for checking deformation (1 to 100 %).
No (50%)
(2) FBGA
Allowable setting range/Description
Setting items
Minimum Maximum
Default
value
1
Pitch (lead pitch) 0.35 mm (Note 4) 2.00 mm None
2
Wd (lead width) 0.14 mm (Note 5) 0.63 mm None
3
Bot., R, Top, L (number of
leads on each side)
4 51 (Note 1) None
4
Missing Start/No (First
missing lead/Number of
missing leads)
Up to three blocks of missing leads can be set. 0
5
Contrast
Select one of the settings: “All balls” and “All land”. (Notes 2
and 3)
All balls
6
Base Style
Select one of the settings: “Standard”, “Index mark 4
corner”, “Index mark 3 corner”, “Index mark 2 corner”, “Index
mark 1 corner”, “Outer belt type mark” and “Mark overspill
type”.
Standard
7
Ball Pattern
Select one of the settings: “Browse”, “Edit”, “Standard
BGA”, “Peripheral BGA”, “Staggered std. BGA (More out)”,
“Staggered per. BGA (More out)”, “Staggered std. BGA
(Fewer out)” and “Staggered per. BGA (Fewer out)” (*).
None
8
NumLn
For a peripheral ball pattern, set the number of lines on which
balls are located with being viewed from the outside.
None
9
Diameter/Level
Select “Yes” or “No” to check the diameter of a ball and set
the level for checking the diameter (1 to 100 %)
No (50%)
10
Variant/Level
Select “Yes” or “No” to check deformation of a ball and set
the level for checking deformation (1 to 100 %).
No (50%)
Note: For a BGA, meaning of some setting items is changed: from “lead pitch” to “ball pitch”,
“lead width” to “ball width”, and “number of leads” to “number of balls on the outer frame”.
