Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
12
4.1.3 Embedded Software
You will find the used eSW versions listed in the eSW_Firmware_Files.txt file in the Documentation
directory on the installation CD.
The hardware status of a subsystem is identified by the 3rd digit in the file name.
The example below shows the file name of the BIOS for the main axes of the X-Series:
File name Hardware status
A0
300200.bhx A 363
A0
400309.bhx A 364
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
13
4.2 SIPLACE X-Series and SIPLACE D3 Hardware Components 3
NOTICE
The hardware configuration of the station computer and the optional Vision computer can
only be combined with a particular hardware configuration for the machine controller.
See the following table for details.
Station computer Machine controller Vision computer
(with 3D coplanarity sensor
option r)
SMP16-CPU086 SMP16-CPU076
SMP16-CPU086 SMP16-CPU086
SIMATIC Box PC 627 SIMATIC Box PC 627
SIMATIC Box PC 627
Table 4-1: Possible combinations of station computer and Vision computer with the machine controller
4.2.1 Station Computer
Name SMP16-CPU086
CPU / clock frequency P M / 1,6 GHz
RAM 768 MB
Hard disk 40 GB
External DVD drive No
Serial interfaces 2
USB interfaces and external USB hub Yes
Network 1 x 10/100Base-T
2 x 10Base-T
6-port hub
Table 4-2: Station computer hardware (previous configuration of SIPLACE X-series and SIPLACE D3)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces
1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-3: Station computer hardware (current configuration of SIPLACE X-series and SIPLACE D3)
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
14
4.2.2 Machine Controller
Name SMP16-CPU076
CPU / clock frequency Celeron / 650 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive No
Floppy drive 3.5", 1.44 MB
USB interfaces and external USB hub Yes
Network 1 x 10/100Base-T
Table 4-4: Machine controller hardware (previous configuration of SIPLACE X-series)
Name SMP16-CPU086
CPU / clock frequency Intel M / 1600 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive No
USB interfaces and external USB hub Yes
Network 1 x 10/100Base-T
Table 4-5: Machine controller hardware (previous configuration of SIPLACE X-series and SIPLACE D3)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-6: Machine controller hardware (current configuration of SIPLACE X-series and SIPLACE D3)
