Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
16
4.3 SIPLACE D1 / D1i, D2 / D2i, and D4 / D4i Hardware Components
NOTICE
The machine computer and Vision computer software can optionally be used in one-
computer operation on a Box PC 627B.
4.3.1 Station Computer
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-8: Station computer hardware (SIPLACE D-series)
4.3.2 Machine Controller
Name SIMATIC Microbox 420
CPU / clock frequency Pentium III / 933 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-9: Machine controller hardware (SIPLACE D-series)
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
17
4.4 SIPLACE CA-Series Hardware Components
NOTICE
The hardware configuration of the station computer and the optional Vision computer can
only be combined with a particular hardware configuration for the machine controller.
See the following table for details.
Station computer Machine controller Vision computer
(with 3D coplanarity sensor
option)
SIMATIC Box PC 627 SIMATIC Box PC 627 SIMATIC Box PC 627
4.4.1 Station Computer
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-10: Station computer hardware (configuration of SIPLACE CA-series)
4.4.2 Machine Controller
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-11: Machine controller hardware (configuration of SIPLACE CA-series)
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
18
4.4.3 Vision Computer (Optional)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-12: Vision computer hardware (optional for SIPLACE CA3 with 3D coplanarity sensor)
