Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
14
4.2.2 Machine Controller
Name SMP16-CPU076
CPU / clock frequency Celeron / 650 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive No
Floppy drive 3.5", 1.44 MB
USB interfaces and external USB hub Yes
Network 1 x 10/100Base-T
Table 4-4: Machine controller hardware (previous configuration of SIPLACE X-series)
Name SMP16-CPU086
CPU / clock frequency Intel M / 1600 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive No
USB interfaces and external USB hub Yes
Network 1 x 10/100Base-T
Table 4-5: Machine controller hardware (previous configuration of SIPLACE X-series and SIPLACE D3)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-6: Machine controller hardware (current configuration of SIPLACE X-series and SIPLACE D3)
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
15
4.2.3 Visionrechner (optional)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-7: Vision computer hardware (optional for SIPLACE X2 and X3 with 3D coplanarity sensor)
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
16
4.3 SIPLACE D1 / D1i, D2 / D2i, and D4 / D4i Hardware Components
NOTICE
The machine computer and Vision computer software can optionally be used in one-
computer operation on a Box PC 627B.
4.3.1 Station Computer
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-8: Station computer hardware (SIPLACE D-series)
4.3.2 Machine Controller
Name SIMATIC Microbox 420
CPU / clock frequency Pentium III / 933 MHz
RAM 256 MB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-9: Machine controller hardware (SIPLACE D-series)
