Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
18
4.4.3 Vision Computer (Optional)
Name SIMATIC Box PC 627
CPU / clock frequency Pentium M / 2 GHz
RAM 1 GB
Hard disk 40 GB
External DVD drive Yes
Serial interfaces 1
USB interfaces and external USB hub Yes
Network 2x 100 MBit
Table 4-12: Vision computer hardware (optional for SIPLACE CA3 with 3D coplanarity sensor)
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
19
4.5 Network Configuration
Station computer
Machine controller
10Base-T
100Base-T
Private network between
station computer,
Vision computer (optional)
and machine controller
SIPLACE LAN
SIPLACE Pro
Twisted Pair TP
(100 MB)
Twisted Pair TP
(10 MB)
Vision computer
(optional)
100Base-T
Figure 4-1: Network connections between the machine and SIPLACE Pro
A separate private network (100 Mbit) is set up between the station computer (and optionally the
Vision computer) and the machine controller via a subnet mask.
Fixed IP addresses for the station computer, Vision computer and machine controller can thus be
assigned for all SIPLACE machines. These IP addresses are not known outside the private
network, for instance in the SIPLACE LAN or customer LAN.
These IP addresses need not be further configured by the operator while the station software is
being installed.
IP address, station computer 192.168.255.249
IP address, machine controller 192.168.255.250
Vision computer IP Address 192.168.255.251
Subnet mask, station computer/machine
controller
255.255.255.248
IP address range, SIPLACE LAN or
IP address range, customer LAN
172.22.xxx.xxx
is configured on-site
Subnet mask for SIPLACE-LAN or
subnet mask for customer LAN
255.255.0.0
is configured on-site
Table 4-13: Network configuration
Station Software 605.03 SP4 / Installation Manual Ausgabe 04/2013 Edition
20
5 Installing the Station Software
NOTICE
The operation system must be installed on the machine controller and Vision computer
before installing the station software.
5.1 Installation Sequence
Back up the MA data
(SITEST)
BIOS update on the station computer
Create setup CD and perform automatic
BIOS update
Install Windows XP operating system
for the station computer
(including installation of the touch screen)
Install SIPLACE software
(station software incl. additional programs)
BIOS settings on the station computer
Create setup CD and perform automatic
BIOS settings
Finish the installation
See section 5.2.
See section 5.2.
See the separate installation manual for installing the
"Windows XP operating system" (item no.
[00194575-xx], [00195327-xx] or [00196737-xx]
respectively)
For calibrating the touch screen, see section 5.3.3.
See sections 5.3 and 5.4.
See section 5.5.
