SIPLACE 80S-20 5 - 3 SIPLACE 80S-20 Circuit Diag rams Spare Parts Electric al System Edition 07/9 7 00301485 -02 TERMI NAL BOA RD VIDEO MULTIP LEXER ( U) 171046 0-Y0554- 000-02 00329585 S01 TO UCH SCR EEN MCM 1405 N D 17…
5 - 2 SIPLACE 80S-20
Spare Parts Electrical System SIPLACE 80S-20 Circuit Diagrams
Edition 07/97
00310192-02 GROUND WIRE (FRAME - COVER) 1710470-Y0632-000-02
00300210-01 HALF BRIDGE RECTIFIER PC BOARD 1710460-Y0001-000-01
00303617-03 HOOD SWITCH OUTPUT 1710460-Y0438-000-03
00320312S01 INPUT / OUTPUT PCB (MIXED) KSP-P218-A32 1710460-Y1001-000-01
00322063-01 INTERFACE FOR WIDTH ADJUSTMENT 1710470-C0955-000-01
00322064-01 INTERFACE FOR WIDTH ADJUSTMENT 1710470-C0956-000-01
00321215S06 INTERMEDIATE DISTRIBUTOR SP6/12 00321215-060101LD3
00321623-01 KEYBOARD SIPLACE TRACKBALL 1710460-Y0982-000-01
00300594-04 LIMIT SWITCH 1710460-Y0406-000-04
00317892-03 LIMIT SWITCH LIFTING TABLE 1710470-Y0449-000-03
00320927S08 MACHINE CONTROLLER 00320927-080101ND3
00308607-01 MICROSWITCH 1006/S4 SERIES 1710460-C0550-003-01
00300595-05 MOTOR PCB IN/MIDDLE TRANSPORT 1710460-Y0407-000-05
00313398-01 MOTOR/LIMIT SWITCH TAPE CUTTER 1710470-Y0441-000-01
00300179-01 MVS BACKPLANE 1 1710491-Y1.7-L
00300180-01 MVS BACKPLANE 2 1710491-Y1.8-L
00321528-01 OPERATOR PANEL I (INPUT) 1710470-C0906-000-01
00321529-01 OPERATOR PANEL II (OUTPUT) 1710470-C0907-000-01
00200034-03 OPTICAL DECOUPLING UNIT 00200034-030101LD3
00316823-01 PCB ILLUMINATION CAMERA BENEATH PORTAL 1710470-Y0094-000-01
00315224-01 PCB OPTICAL MODULE 1710460-L9000-000-01
00300272-04 PLUG IN FOR SERVICE 00300272-040101LD4
00300398-03 POTENTIAL DISTRIBUTION BOARD SERVO UNIT 1710460-Y0026-000-03
00302841-01 POWER SUPPLY (+ - 15V) 1710460-Y0901-001-01
00322117-02 POWER SUPPLY + 5.1V/+ - 12V/+ - 15V/+25V 00322117-020101ND4
00304908-01 PROXIMITY SWITCH 4 mm WITH LED 1710460-Y0409-000-01
00300609-03 PROXIMITY SWITCH: END POSITION X AXIS 1710460-Y0430-000-03
00300601-03 PROXIMITY SWITCH: END POSITION Y AXIS 1710460-Y0424-000-03
00300905-03 PROXIMITY SWITCH: LIMIT Y AXIS BERO 1710460-Y0425-000-03
00300597-02 PROXIMITY SWITCH: STOPPER 1710460-Y0409-000-02
00300593-02 PROXIMITY SWITCH: WIDTH ADJMMT. 1710460-Y0405-000-02
00300167-02 RECTIFIER PC BOARD 30V 00300167-020101LD4
00300169-02 RECTIFIER PC BOARD 60V 00300169-020101LD4
00300168-02 RECTIFIER PC BOARD 6V 00300168-020101LD4
00321406S01 REVOLVER HEAD 10000 1710472-F0901-000-01
00304351-01 SAFETY SWITCH, PROTECTION IP 67 1710460-C3040-110-01
00321524S03 SENSOR Z AXIS BOTTOM 00321524-030202LD4
00321736S03 SERVO AMPLIFIER PC-BOARD TBS 120/2.5S
00321732S02 SERVO AMPLIFIER PC-BOARD TDS 120/12.5X
00321734S02 SERVO AMPLIFIER PC-BOARD TDS 120/1D
00321735S02 SERVO AMPLIFIER PC-BOARD TDS 120/2.5Z
00321733S04 SERVO AMPLIFIER PC-BOARD TDS 120/25Y
00321480-02 SERVO UNIT SIPLACE 80S4 1710470-C0935-000-02
00303585-01 SONAR PROXIMITY SWITCH 1710460-Y0417-000-01
00320863-01 SONAR PROXIMITY SWITCH: PCB CENTER BELT 1710460-Y0462-000-01
00328348S02 STATION COMPUTER SNI SCENIC PROC5
00317891-01 STEP MOTOR CONTROL UNIT (LIFTING TABLE)
00301420-01 STEPPING MOTOR CONTROL UNIT 1710460-Y0010-000-01
00317216-01 STEPPING MOTOR PC-BOARD ESD 1200
00317890-02 STEPPING MOTOR PC-BOARD KS-BE-08/90
00317889-02 STEPPING MOTOR PC-BOARD KS-TGE
00300592-03 STEPPING MOTOR WIDTH CHANGING FACILITY 1710460-Y0404-000-03
00304878-01 SWITCH. ELEMENT FOR 3-PHASE SYSTEM 16A
00320924S03 TCP/IP-INTERFACE KSP-COM223 00320924-030101ND3
00321510-05 TERMINAL BOARD (RIGHTHAND SIDE) 00321510-050201LD3
00301486-02 TERMINAL BOARD VIDEO MULTIPLEXER (SIGN.) 1710460-Y0555-000-02
SIPLACE 80S-20 5 - 3
SIPLACE 80S-20 Circuit Diagrams Spare Parts Electrical System
Edition 07/97
00301485-02 TERMINAL BOARD VIDEO MULTIPLEXER (U) 1710460-Y0554-000-02
00329585S01 TOUCH SCREEN MCM 1405 ND 1710460-Y0983-000-01
00322550-02 TRANSCEIVER CABLE 1710470-Y0687-000-02
00321216S03 VACUUM BOARD SP6/12 00321216-030202LD3
00302926-01 VIDEO MULTIPLEXER SIPLACE 1710460-Y0019-000-01
00304048-01 VILEDON FILTER MAT 225*362
00321525-02 VISION 1710472-Y0020-000-02
5 - 4 SIPLACE 80S-20
Spare Parts Electrical System SIPLACE 80S-20 Circuit Diagrams
Edition 07/97
