Maintenance Preventive Maintenance MTC 2 1 MTC 10/2010 US Edition 10 1.4 Overview of the modules 1 Fig. 1 - 2 Overview of the assemblies a Lifting axis s Feed axis d Unlock device WTC f Driver unit g Driver h Control uni…
Preventive Maintenance MTC 2 Maintenance
10/2010 US Edition 1 MTC
9
1.3 Maintenance schedule
1
1
1
1
1
1
1
1
Interval Location Tools and equipment/
consumables
Perform
ed on
Day Vacuum the feed axis and the feeder
modules
Vacuum cleaner
Empty the waste container Garbage can
Week Clean the rails of the feed axis Ethyl alcohol, lint-free cloths
Clean the cassette guide rails Ethyl alcohol, lint-free cloths
Month Grease the linear guides of the feed axis WD40
2 Month
Check the leaf springs of the WTC interlock
Check the WTCs
Maintain the component feeder table Vacuum cleaner, oilstone,
scissors, lint-free cloths, WD40
Year Inspection of the assemblies
These maintenance steps
are to be performed by
instructed service stuff.
Greasing the linear guides
2 Years Change of lubrication system
Change of batteries
Inspection of toothed belts
Maintenance Preventive Maintenance MTC 2
1 MTC 10/2010 US Edition
10
1.4 Overview of the modules
1
Fig. 1 - 2 Overview of the assemblies
a Lifting axis
s Feed axis
d Unlock device WTC
f Driver unit
g Driver
h Control unit of the MTC
