Maintenance Preventive Maintenance MTC 2 1 MTC 10/2010 US Edition 8 1.2 Everything needed for maintenance The following lists of materials contain all of the to ols, equipm ent and consumables r equired to maintain the M…
Preventive Maintenance MTC 2 Maintenance
10/2010 US Edition 1 MTC
7
1.1.1 Explanation of Symbols
1
1
Tools and expendable materials required 1
1
1
1
Note 1
1
1
1
Tip 1
1
1
1
Caution 1
1
1
1
1.1.2 Basic Rules during Maintenance Work
CAUTION
Never use compressed air to clean assemblies inside the machine. 1
Record the maintenance work performed in the maintenance schedule. We recommend that work
be performed in the order indicated in the maintenance schedule. 1
To save time while cleaning, perform the maintenance work on the SIPLACE at the same time as
the cleaning, complying with the safety instructions in the process. 1
1
1
1
1
1
Maintenance Preventive Maintenance MTC 2
1 MTC 10/2010 US Edition
8
1.2 Everything needed for maintenance
The following lists of materials contain all of the tools, equipment and consumables required to
maintain the MTC. 1
Do not use any solvents for cleaning, just ethyl alcohol. 1
Just apply all lubricants sparingly and selectively. 1
1.2.1 Tools and equipment
Prepare the following tools and equipment for the maintenance work.:
1.2.2 Consumables
Set out the following consumables for the maintenance work:
1.2.3 Spare parts
Set out the following spare parts for the maintenance work:
Equipment Item no.
Garbage can
Vacuum cleaner
Whetstone / oilstone
Scissors
Consumables Item no.
Soft, lint-free cloths
Ethyl alcohol
WD40, 400 ml 00325833-01
Spare parts Item no.
Interlock WTC 00359419-xx
Preventive Maintenance MTC 2 Maintenance
10/2010 US Edition 1 MTC
9
1.3 Maintenance schedule
1
1
1
1
1
1
1
1
Interval Location Tools and equipment/
consumables
Perform
ed on
Day Vacuum the feed axis and the feeder
modules
Vacuum cleaner
Empty the waste container Garbage can
Week Clean the rails of the feed axis Ethyl alcohol, lint-free cloths
Clean the cassette guide rails Ethyl alcohol, lint-free cloths
Month Grease the linear guides of the feed axis WD40
2 Month
Check the leaf springs of the WTC interlock
Check the WTCs
Maintain the component feeder table Vacuum cleaner, oilstone,
scissors, lint-free cloths, WD40
Year Inspection of the assemblies
These maintenance steps
are to be performed by
instructed service stuff.
Greasing the linear guides
2 Years Change of lubrication system
Change of batteries
Inspection of toothed belts
