FX-3R Maintenance Guide 13-38 Rev . 1.00 • XL specification Applicable cable Connection destination Part No. Part name Name of destination Connector No. Operation specifications 40002241 BU LOCK SENS ASM 40047916, 40047 …

100%1 / 251
FX-3R Maintenance Guide
13-37
Rev. 1.00
[Backup related cable assemblies]
The backup related cable assemblies may vary depending on the ST/EN specifications.
Connect them as shown in the table.
Table 13-7-1-2 Backup Related Cable Assemblies
• L specification
Applicable cable Connection destination
Part No. Part name Name of destination Connector No.
Operation
specifications
40002241 BU LOCK SENS ASM 40047916, 40047926 CN446 EN only
40047849 SV WIRE ASM 40047847, 40047848 EV ST only
40048260 SV WIRE ASM (EN)
40047847, 40047848
40048259
EV
SAFE
EN only
40048259 BU LOCK RELAY CABLE ASM (EN) Safety unit CN912 EN only
40048076 BU MOTOR ASM
40047831, 40047832
40047835, 40047836
CN657, CN667
Common for ST/EN
E94337290A0 BU ENC ASM 40047841, 40047842 CN658, CN668 Common for ST/EN
40047831 BU-L MOTOR CABLE ASM
−−−−−
ST only
40047835 BU-L MOTOR CABLE ASM (EN)
−−−−−
EN only
40047799 BU DRV PWR CABLE (L) ASM
−−−−−
ST only
40047800 BU DRV PWR CABLE (L) ASM (EN)
−−−−−
EN only
40047855 BU DRV FG CABLE (L) ASM
−−−−−
ST only
40047856 BU DRV FG CABLE (L) ASM (EN)
BU-L stepping driver
−−−−−
EN only
40047832 BU-R MOTOR CABLE ASM
−−−−−
ST only
40047836 BU-R MOTOR CABLE ASM (EN)
−−−−−
EN only
40047803 BU DRV PWR CABLE (R) ASM
−−−−−
ST only
40047804 BU DRV PWR CABLE (R) ASM (EN)
−−−−−
EN only
40047859 BU DRV FG CABLE (R) ASM
−−−−−
ST only
40047860 BU DRV FG CABLE (R) ASM (EN)
BU-R stepping driver
−−−−−
EN only
FX-3R Maintenance Guide
13-38
Rev. 1.00
• XL specification
Applicable cable Connection destination
Part No. Part name Name of destination Connector No.
Operation
specifications
40002241 BU LOCK SENS ASM 40047916, 40047926 CN446 EN only
40047849 SV WIRE ASM 40047847, 40047848 EV ST only
40048260 SV WIRE ASM (EN)
40047847, 40047848
40048259
EV
SAFE
EN only
40048259 BU LOCK RELAY CABLE ASM (EN) Safety unit CN912 EN only
40048076 BACK UP MOTOR ASM
40047831, 40047832
40089951, 40089952
CN657, CN667 Common for ST/EN
E94337290A0 BU ENC ASM 40089920, 40089921 CN658, CN668 Common for ST/EN
40089916 BU-L MOTOR CABLE ASM
−−−−−
ST only
40089951 BU-L MOTOR CABLE ASM (EN)
−−−−−
EN only
40089908 BU DRV PWR CABLE (L) ASM
−−−−−
ST only
40089947 BU DRV PWR CABLE (L) ASM (EN)
−−−−−
EN only
40047855 BU DRV FG CABLE (L) ASM
−−−−−
ST only
40047856 BU DRV FG CABLE (L) ASM (EN)
BU-L stepping driver
−−−−−
EN only
40089917 BU-R MOTOR CABLE ASM
−−−−−
ST only
40089952 BU-R MOTOR CABLE ASM (EN)
−−−−−
EN only
40089910 BU DRV PWR CABLE (R) ASM
−−−−−
ST only
40089949 BU DRV PWR CABLE (R) ASM (EN)
−−−−−
EN only
40047859 BU DRV FG CABLE (R) ASM
−−−−−
ST only
40047860 BU DRV FG CABLE (R) ASM (EN)
BU-R stepping driver
−−−−−
EN only
FX-3R Maintenance Guide
13-39
Rev. 1.00
[Auto width adjustment related cable assemblies]
The auto width adjustment related cable assemblies may vary depending on the ST/EN
specifications.
Connect them as shown in the table.
Table 13-7-1-3 Auto Width Adjustment Related Cable Assemblies
• L specification
Applicable cable Connection destination
Part No. Part name Name of destination
Connector No.
Operation
specifications
40048077 AWC MOTOR ASM
40047843, 40047844
40047833, 40047834
40047837, 40047838
CN659/660
Common for
ST/EN
40047833 AWC-L MOTOR CABLE ASM
−−−−−
ST only
40047837 AWC-L MOTOR CABLE ASM (EN)
−−−−−
EN only
40047797 AWC DRV PWR CABLE (L) ASM
−−−−−
ST only
40047798 AWC DRV PWR CABLE (L) ASM (EN)
−−−−−
EN only
40047853 AWC DRV FG CABLE (L) ASM
−−−−−
ST only
40047854 AWC DRV FG CABLE (L) ASM (EN)
AWC-L stepping
driver
−−−−−
EN only
40047834 AWC-R MOTOR CABLE ASM
−−−−−
ST only
40047838 AWC-R MOTOR CABLE ASM (EN)
−−−−−
EN only
40047801 AWC DRV PWR CABLE (R) ASM
−−−−−
ST only
40047802 AWC DRV PWR CABLE (R) ASM (EN)
−−−−−
EN only
40047857 AWC DRV FG CABLE (R) ASM
−−−−−
ST only
40047858 AWC DRV FG CABLE (R) ASM (EN)
AWC-R stepping
driver
−−−−−
EN only
• XL specification
Applicable cable Connection destination
Part No. Part name Name of destination
Connector No.
Operation
specifications
40048077 AWC MOTOR ASM
40089844, 40089845,
40089842, 40089843,
40089953, 40089954
CN659/660
Common for
ST/EN
40089842 AWC-L MOTOR CABLE ASM XL
−−−−−
ST only
40089953 AWC-L MOTOR CABLE ASM (EN) XL
−−−−−
EN only
40089907 AWC DRV PWR CABLE (L) ASM
−−−−−
ST only
40089946 AWC DRV PWR CABLE (L) ASM (EN)
−−−−−
EN only
40047853 AWC DRV FG CABLE (L) ASM
−−−−−
ST only
40047854 AWC DRV FG CABLE (L) ASM (EN)
AWC-L stepping driver
−−−−−
EN only
40089843 AWC-R MOTOR CABLE ASM XL
−−−−−
ST only
40089954 AWC-R MOTOR CABLE ASM (EN) XL
−−−−−
EN only
40089909 AWC DRV PWR CABLE (R) ASM
−−−−−
ST only
40089948 AWC DRV PWR CABLE (R) ASM (EN)
−−−−−
EN only
40047857 AWC DRV FG CABLE (R) ASM
−−−−−
ST only
40047858 AWC DRV FG CABLE (R) ASM (EN)
AWC-R stepping
driver
−−−−−
EN only
