User Manual SIPLACE HF Series 1 Introduction
Software Version SR.505.xx 05/2004 US Edition 1.4 Danger notes
21
Service engineers 1
This class is intended for engineers from SIEMENS. They are trained to carry out servicing work
and to upgrade and retrofit the placement system. 1
1.4 Danger notes
WARNING 1
– A thorough knowledge of the relevant part of this User Manual is required before carrying out
any work on the machine.
– All work must be carried out by appropriately trained and qualified personnel.
– All warning, caution and danger notes MUST be observed.
– In addition, read through chapter 2 of the user manual carefully.
1.5 Liability of the manufacturer/supplier
We draw your attention to the fact that this user manual only contains descriptive and explana-
tory material and does not include any contractual conditions or undertakings. All obligations of
Siemens AG proceed from the conclusion of the contract concerned, under which you have the
machine described herein. This applies in particular to all statements regarding performance or
service life and the agreed liability for faults or defects. The provisions of the contract regarding
the liability for faults or defect are neither extended nor restricted by any statements in this user
manual. 1
1 Introduction User Manual SIPLACE HF Series
1.6 EU Declaration of Conformity Software Version SR.505.xx 05/2004 US Edition
22
1.6 EU Declaration of Conformity
The product/device described below 1
product: Automatic Placement System
type: SIPLACE HF SIPLACE HF/3
item no.: 119600 119650 1
manufactured by 1
SIEMENS AG
L&A
Rupert-Mayer-Str. 44
D-81379 Munich 1
conforms to the relevant provisions of: 1
– Directive 98/37/EC of the European Parliament and of the Council of June 22, 1998 on the
approximation of the laws of the Member States relating to machinery
– Council Directive 89/336/EEC of May 3, 1989 on the approximation of the laws of the Mem-
ber States relating to electromagnetic compatibility
The product(s) identified above comply with the requirements of the above EU directive by meet-
ing the following standards: 1
EN 292-1, EN 292-2, EN 294, EN 349, EN 418, EN 811, EN 1050, EN 60204-1, EN 60825-1,
EN 61000-3-2/3, EN 61000-4-2/3/4/5/6/8, BGV A1
1)
, BGV A2
1)
1
1.7 Revision index
1
1
1
1) National specifications
This declaration certifies the compliance with the indicated directives but implies no warranty of properties.
The safety instructions of the accompanying product documentation shall be observed.
Manual Software version Edition
Preliminary user manual
5.05 11/2003 DE
First edition User Manual
5.05 05/2004 US
User Manual SIPLACE HF Series 1 Introduction
Software Version SR.505.xx 05/2004 US Edition 1.8 Abbreviations
23
1.8 Abbreviations
1
1
C&P 1 Collect&Place 1
C&P12 1 Collect&Place head with 12 segments 1
C&P6 1 Collect&Place head with 6 segments 1
CO 1 Component 1
DCA 1 Direct Chip Attach 1
ESD 1 Electrostatic Sensitive Device 1
FC 1 Flip chip 1
GND 1 Ground 1
IC 1 Integrated circuit 1
MTC 1 Matrix tray changer 1
OSC 1 Odd Shaped Components 1
P&P 1 Pick&Place 1
PCB 1 Printed circuit board 1
SMD 1 Surface Mounted Device 1
TH 1 TwinHead 1
WT 1 Waffle-pack tray 1
WTC 1 Waffle-pack tray carrier 1
