Section 15 01-57787-03 TP DISPENSER B
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING ASM CUSTOMER SERVICE DRAWINGASM CUSTOMER SERVICE DRAWING
21 345678
87654312
B
A
C
D
E
F F
E
D
C
A
B
CS DW G NO.
OF
REV
DESCRIPTION
SHEET
DESCRIPTION
NO.
PART
NO.
PART
INFORMATION AND IS NOT TO BE USED OR
DO NOT SCALE
REPRODUCED WITHOUT PERMISSION OF
THIS DRAWING CONTAINS PROPRIETARY
ALL CAPACITORS ARE IN
µ
F
ALL RESISTORS ARE IN
Ω
ALL DIM A
RE IN mm
UNLESS OTHERWISE SPECIFIED
ASM
Assembly Automation Ltd.
A S M
DWG REV
TP DISPENSER
01-57787-03
CS-01-57787-03
11
FROM: 01-57787-03_B_2011.02.22
B1
B
ITEM PART NO. DESCRIPTION QTY.
1 01-57788 SOLENOID MODULE 1
2 01-69087 HIPEC DISPENSER UNIT BOX ASSY 1
3 02-62566 TP DISPENSER MANUAL BUTTON ASSY 1
4 02-62567 TP DISPENSER PWR LED ASSY 1
5 02-62568 TP DISPENSER DISP LED ASSY 1
6 02-66064 PRESSURE REGULATOR ASSY 1
7 03-21586 TP DISPENSER IO BOARD 1
8 03-21587-01 TP DISPENSER SENSOR BOARD(502G) 1
9 26-E80956 SUPPORT SHAFT FOR CONTROL BOARD 2
10 26-E80962 SOLENOID VALVE SUPPORT 1
11 26-E83182 TP DISPENSER CONTROL BOARD BLANKET 1
12 26-E83269 SOLENOID VALVE S070C MOUNTING PLATE 1
13 26-E86868 AIR TANK SUPPORT (LEFT) 1
14 26-E86869 AIR TANK SUPPORT (RIGHT) 1
15 26-E86870 AIR TANK COVER 2
16 26-E86871 CONTROL BOARD I/O BRACKET 2
17 26-E90174 CKD REGULATOR MOUNTING STRIP 2
18 26-F08174 4MM TUBE LOCK FOR SENSOR BOARD 1
19 26-F26493 TP CONTROL BOARD BACK PLATE 1
20 26-F27884 FLOW CONTROLLER MOUNTING ON ARCHERFISH 1
21 30-00108 FLOW CTL D-VALVE AS1201FM-M5-06 1
22 30-52344 VACUUM VALVE ZH07DS-06-06-06 1
23 31-00039 BULKHEAD FEMALE UNION:KQE06-01 1
24 31-40039 CONNECTOR SOCKET KD3-1/8-A 1
25 31-40154 STRAIGHT TUBE FITTING CPPE3-M5 1
26 31-40156 MALE ELBOW CONNECTOR KQL04-M5 1
27 31-40198 MALE ELBOW KJL06-01S-X20 [20B3] 3
28 31-40457 BULKHEAD UNION KQE08-00 1
29 31-40719 MALE ELBOW FITTING KQ2L06-02S 2
30 33-00156 SILENCER AN203-KM8 1
31 33-40043 AIR RESERVOIR VZS-0.1 2
32 820-60061 S HD CAP SCW M4X50 4
33 820-86084 MR100 S HD CAP SCW M5X16 2
34 831-40080 QUICK COUPLING PLUG KS3-CK-4, 3326 1
Assembly View
10
7
8
11
13
15
18
21
24
26
27
28
29
30
32
34
1
3
4
5
9
14
25
20
23
2
16
19
22
33
6
17
31
A
DETAIL A
12
