Tabl e of D i f f er e nt Type of Tube Pre s s u re Air Tu b e : T ype of T ube P / N C ol or P .D 12 31- 50033 T r ans l uce nt B l ue P .D 10 31- 50035 T r ans l uce nt B l ue P .D 8 31- 40271 T r ansl uce nt B l ue P …
AD8312 WIRING & M/C CONFIGURATION
A-288
1 06-GE00706 AD8312 GENETIC CHART A
AD8312 WIRING & M/C CONFIGURATION
A-299
1 06-GE00706 AD8312 GENETIC CHART A
Table of Different Type of Tube
Pressure Air Tube:
Type of Tube P/N Color
P.D12 31-50033 Translucent Blue
P.D10 31-50035 Translucent Blue
P.D8 31-40271 Translucent Blue
P.D6 31-40234 Translucent Blue
P.D4 31-50009 Translucent Blue
P.D3 31-50022 Translucent Blue
Vacuum Tube:
Type of Tube P/N Color
V.D6 31-50048 Transparency
V.D4 31-50029 Transparency
V.D3 31-50016 Transparency
Soft Tube:
V.D3S 31-40659 Translucent natural
AD8312 WIRING & M/C CONFIGURATION
A-30
1 06-GE00706 AD8312 GENETIC CHART A
