02-74606 (AD8312 HIPEC#1 ASSY 02-74607 AD8312 HIPEC#2 ASSY 02-74608 AD8312 POWER SYSTEM ASSY 02-74609 AD8312 DRIVER ASSY 02-62604-56 VISION PC ASSEMBLY
LOCATION OF MAIN MODULES
Scetion 2
Scetion 3
Scetion 4
Scetion 5
Scetion 6
Scetion 7
Scetion 8
Scetion 9
Scetion 10
Scetion 11&12$13
Scetion 1
02-74606
(AD8312 HIPEC#1 ASSY
02-74607
AD8312 HIPEC#2 ASSY
02-74608
AD8312 POWER
SYSTEM ASSY
02-74609
AD8312 DRIVER ASSY
02-62604-56
VISION PC ASSEMBLY
02-74469
(UI83) LED SIGNAL TOWER
LIGHT W/ BUZZER
05-00710
HP 19" WIDESCREEN LCD
05-00390
PS/2 + USB INTERFACE
OPTICAL MOUSE WITH
05-00678
MINI KEYBOARD USB & PS2
Scetion 15
