- 5 -
High Maintainability
① The maintainability has been enhanced by displaying the screens of pick-up frequencies
per nozzle and of X/Y axis traveling distances to call a checking time, in addition to the
hour meter (energized hours).
② Protecting the passwords has hierarchically stratified the maintenance levels to increase
a degree of freedom in setting the machines.
③ A head filter is installed in the upper part of the head to facilitate replacement.
Response to the safety standards
① The machine marked with Europe CE directive is added to the line-up.
Environment and energy saving
① Power consumption has been reduced by 25% by adopting AC servomotor and ball screw
control for the axis control compared with the former machine. The energy efficiency has been
thus improved. (Compared with KE-2080)
- 6 -
3.
System Configuration
3.1. KE-3020 System Configuration
Power unit
Cabinet
Emergency stop button
ATX power supply (with UPS function)
Leakage breaker *1
CPU
Liquid crystal display (Touch panel)
Mouse
HOD
SSD
Communication port (Ethernet board)
Touch panel
Rear side operation unit *1
DVD/CD-ROM drive (USB)
FD drive (USB)
Keyboard
USB port
Signal tower with the buzzer
Mini signal light *1
I/O control CPU
Motor control unit
X-Y control unit
Placing head
Laser recognition head (LNC60)
IC head (CDS)
Offset Correction Camera (OCC) L,R
Height Measurement System (HMS)
Bad Mark Reader (BMR) *1
Vacuum pump
Main line filter *1
Automatic PWB transportation Width adjustment device
Pin reference *1
L-Wide *1, *3
Feeder float detecting function
SOT direction check function *1
Components Verification System (CVS)
*1
Feeder position indicator function (FPI) *1
Flexible Calibration System (FCS)
External Programming Unit (EPU)
Intelligent Shopfloor Solutions (IS)
Intelli Stocker *2
Connector bracket *1
Trash box
Intelli feeder trolley for mechanical feeder *2
Tape feeder, Bulk feeder, Stick feeder *2
IC collection belt
Tape cutter unit *1
Component supply unit Tape feeder, Stick feeder *2
Tray feed device
MTC
（
TR-6DNX/6DXLX, 6SNX/6SXLX
）
MTS (TR-5DNX/SNX)
DTS (Dual Tray Server)
Tray holder
Super Foot *1
Caster *1
*3
MNVC *1
High-resolution camera (vision field: 27 mm) *1
IC collection belt
Feeder trolley for electric feeder(EF)/(RF)*7
Intelli feeder trolley for electric feeder *2
TR-1SNR for mechanical feeder bank
TR-1EB for electric feeder bank
Tray holder for mechanical feeder bank
Tray holder for electric feeder bank
Coplanarity function
*1
Load calibration stage *1
Offset Placement After Solder Screen-printing *1
KE-3020
Ionizer
*1
Component DB function*4
Mechanical feeder bank
Automatic Tool Changer
(ATC)
Air pressure unit piping system
Load control nozzle
Placement station
PWB conveyor unit
Outline reference
VCS camera
Standard camera (vision field: 54
mm)
Feeder trolley for mechanical feeder
Batch feeder change function *1
Batch feeder change function *1
Electric feeder bank *1
Vision Centering System(VCS)
Component supply unit
Fluxer *1
Feeder bank for both a
mechanical feeder and an
electric feeder *1 *5
Tape reel attaching platform
ETF Tape reel attaching platform(EF)/(RF)
RF-ETF attachment *6
Production support system (IS Lite,JaNets)
Production management system (IFS-NX)
Equipment or a function surrounded by a dashed line is optional.
*1 An option indicated with an asterisk "*" is to be mounted on the main unit at
the factory.
*2 To use the production management system, Applicable to FRID is required.
(factory-set option).
*3 It is available for only machines handling L-PWB.
*4 Another PC is necessary to use Component DB function.
*5 See the description of each feeder bank for an option to be shared (only the
function for a feeder exchange trolley is supported).
*6 Attach this component when electric feeders are used by a feeder trolley
(RF).(If you use the EF series electric feeder attachment, non-teaching and
synchronous adsorption guarantee are excluded.)
*7 It's necessary to change the cutter unit to the latest to use "Feeder exchange
trolley RF".
Offline power supply for an electric bank (PW01/02)
- 7 -
3.2. KE-3020R System Configuration
Power unit
Cabinet
Emergency stop
button
ATX power supply (with UPS function)
Leakage breaker *1
CPU
Liquid crystal display (Touch panel)
Mouse
HOD
SSD
Communication port (Ethernet board)
Touch panel
Rear side operation unit *1
DVD/CD-ROM drive (USB)
FD drive (USB)
Keyboard
USB port
Signal tower with the buzzer
Mini signal light *1
I/O control CPU
Motor control unit
X-Y control unit
Placing head
Laser recognition head (LNC60)
IC head (FMLA)
Offset Correction Camera (OCC) L,R
Height Measurement System (HMS)
Bad Mark Reader (BMR) *1
Vacuum pump
Main line filter *1
Air pressure unit piping system
PWB conveyor unit
Placement station
Automatic PWB transportation Width adjustment device
Outline reference
Pin reference *1
L-Wide *1, *3
Feeder float detecting function
SOT direction check function *1
Components Verification System (CVS)
*1
Feeder position indicator function (FPI) *1
Flexible Calibration System (FCS)
External Programming Unit (EPU)
Intelligent Shopfloor Solutions (IS)
Intelli Stocker *2
Batch feeder change function *1
Connector bracket *1
Trash box
Feeder trolley for mechanical feeder
Intelli feeder trolley for mechanical feeder *2
Component supply unit
IC collection belt
Batch feeder change
function *1
Tape cutter unit *1
Component supply unit Tape feeder, Stick feeder *2
Tray feed device
MTC
（
TR-6DNX/6DXLX, 6SNX/6SXLX
）
MTS (TR-5DNX/SNX)
DTS (Dual Tray Server)
Tray holder
Super Foot *1
Caster
*1*3
VCS camera
MNVC *1
Vision Centering System(VCS)
Standard camera (vision field: 54
mm)
High-resolution camera (vision field: 27 mm) *1
IC collection belt
Feeder trolley for electric feeder (EF)/(RF)*7
Intelli feeder trolley for electric feeder *2
TR-1SNR for mechanical feeder bank
TR-1EB for electric feeder bank
Tray holder for mechanical feeder bank
Tray holder for electric feeder bank
Coplanarity function
*1
Load calibration stage *1
Load control nozzle
Offset Placement After Solder Screen-printing *1
KE-3020R
Ionizer
*1
Component DB function *4
Automatic Tool Changer
(ATC)
Mechanical feeder bank
Electric feeder bank *1
Tape feeder, Bulk feeder, Stick feeder *2
Fluxer *1
Feeder bank for both a
mechanical feeder and an
electric feeder *1 *5
Tape reel attaching platform
ETF Tape reel attaching platform (EF)/(RF)
Equipment or a function surrounded by a dashed line is
optional.
*1 An option indicated with an asterisk "*" is to be mounted on the
main
unit at the factory.
*2 To use the production management system, Applicable to FRID is
required. (factory-set option).
*3 It is available for only machines handling L-PWB.
*4 Another PC is necessary to use Component DB function.
*5 See the description of each feeder bank for an option to be shared
(only the function for a feeder exchange trolley is supported).
*6 Attach this component when electric feeders are used by a feeder
trolley (RF).(If you use the EF series electric feeder attachment,
non-teaching and synchronous adsorption guarantee are excluded.)
*7
It's necessary to change the cutter unit to the latest to use "Feeder
exchange trolley RF".
Production support system (IS Lite,JaNets)
Production management system (IFS-NX)
RF-ETF attachment *6
Offline power supply for an electric bank (PW01/02)
