- 36 -
6.3. Tape Feeder
6.3.1. Tape feeder for mechanical bank
(
1) CTFR
1) List of specifications
Product
code
Tape type
Feeding pitch
Number of
pins
posting
Diameter of
a reel
Typical component
type
Paper Embossed
CF03HPR
○
－
2mm
Two
φ180 mm
0603
CF05HPR
○ －
1005
CF08HER
－ ○
Two-terminal diode
CF081PR
○ －
4m
m
1608, 2012, 3216
CF081ER
－ ○
SOT
CF8L1PR
○ －
φ180 t
o φ380
mm
1608, 2012, 3216
CF8L1ER
－ ○
SOT
CN05HPR
○
－
2mm
One
φ180mm
1005
CN08HER
－
○
Two-terminal diode
CN081CR
○ ○
4m
m
1608, 2012, 3216
CN8L1CR
○ ○
φ180 t
o φ380
mm
1608, 2012, 3216
* For a tape feeder designed for both paper and emboss, contact our sales person.
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC 60286-3:2007.
*The RFID correspondence of the tape feeder is necessary for using the RFID function of the production
management system.
2) Common specifications
1
Power supply/air supply
None
2
Outer
dimensions
C*0***R
L=602mm, H=208m, W=16.2mm
C*8L1*R
L=683mm, H=431mm, W=16.5mm
3
Mass
C*0***R
1.2 kg (Excluding a reel)
C*8L1*R
1.9 kg (Excluding a reel)
4
Component transport method
Ratchet drive system
3) O
ptions
① Bar code tag
This tag is used to paste a bar code mark onto the rear edge of a tape feeder.
Even after you install a tape feeder on the feeder bank, the pasted bar code can
be read easily.
②
RFID tag mounting kit
By adding a RFID tag to a CTF type o
f tape feeder in use, you can conduct a
feeder management with the production management system.
- 37 -
(2) ATF
For splicing of component feed tape (tape splicing), this tape feeder permits a
component feed during production.
1) S
pecifications
① 8mm
Product code
Tape type
Feeding
pitch
Number of pins
posting
Diameter
of a reel
Typical component
type
Paper Embossed
AQ02HP See
Note 1
○ － 2mm
Two
φ180 mm
0402 only
AF05HP ○ －
2m
m
1005
AF08HE － ○ Two-terminal diode
AF081P ○ －
4m
m
1608, 2012, 3216
AF081E － ○ SOT
AN05HP ○ －
2mm
One
1005
AN08HE － ○ Two-terminal diode
AN081P ○ －
4m
m
1608, 2012, 3216
AN081E － ○ SOT
Note 1: This tape feeder does not support splicing.
* For a tape feeder designed for both paper and emboss, contact our sales person.
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
* T
he RFID correspondence of the tape feeder is necessary for using the RFID function of th
e
pr
oduction management system.
② 12mm to 24mm
Product code Feed pitch
Pick-up position
(Y direction)
Applicable
component emboss
width
Applicable
component
emboss depth
AF121S 4mm
132mm
8.3 mm or less
17 mm or less
AF122S 8mm
AF123S 12mm
AF12FS 4/8/12mm
AF12NS 4/8/12mm
AF161S
4mm
12.2 mm or less
AF162S 8mm
AF163S 12mm
AF16FS 4/8/12/16mm
AF16NS 4/8/12mm
AF242S 8mm
20.2 mm or less
AF243S 12mm
AF244S 16mm
AF245S 20mm
AF246S 24mm
AF24FS 8/12/16/20/24mm
AF24NS 8/12mm
AF24FS-OP
8/12/16/20/24mm
114 mm
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC
60286-3:2007.
* The RFID correspondence of the tape feeder is necessary for using the RFID function of the
production management system..
- 38 -
2) Common specifications
8mm 12mm/16mm 24mm
1 Power supply/air supply None
2 Dimensions L=645mm,
H=213mm,
W=16.8mm
L=693mm,
H=472mm,
W=31.5mm
L=693mm,
H=472mm,
W=40mm
3 Mass (Excluding a reel) 1.8 kg or less 2.45kg or less 2.6kg or less
4 Component transport method Ratchet drive system
3) O
ptions
① Bar code tag (8mm only)
This tag is used to paste a bar code mark onto the rear edge of a tape feeder.
Even after you install a tape feeder on the feeder bank, the pasted bar code can
be read easily.
② Embossed tape spacer
To improve the feed and pick-up stability of the carrier tape for the emboss
component made of a soft and fragile material, this spacer is installed in th
e
em
boss groove of the feeder to support the bottom surface of the carrier tape.
A type for 8 mm feeder, type for both 12 mm and 16 mm feeders, and type for 24
mm feeder are available.
③ Joint tape splicing jig (8mm only)
When you use a JUKI designated joint tape, this jig allows you to paste a joint
tape with glue easily.
④ J
oint tape
This is a tape that splices an old tape reel and a new tape reel.
A dedicated type for each tape width is available.
⑤ S
cissors (Tape cutting jig A, and B)
A positional adjustment between the tape feeder used during the production and
a new tape feeder to be connected can be accurately and quickly made by
cutting the tapes with dedicated scissors when they are spliced.
・Tape cutting jig A: Available for feed pitch (4, 12, 20, 28, 36, 44, 52).
・Tape cutting jig B: Available for feed pitch (8, 16, 24, 32, 40, 48, 56).
⑥ Tag Insert Kit (RFID tag attachment kit)
By attaching a RFID tag on a ATF feeder currently used, you can manage the
feeders with the production management system.
