- 34 -
6.
Component supply unit (Optional)
6.1. List of Feeder Bank Specifications
A
bank is selected from five types shown below, which supplies components.
It is possible to combine with a front bank and/or a rear bank according to your usage.
Bank type
Attachable feeder
type
Attachable feeder
exchange trolley
① Mechanical feeder bank fixed type Mechanical feeder
－
② Electric feeder bank fixed type Electric feeder
－
③
Mechanical feeder bank
feeder exchange trolley type
Mechanical feeder
Mechanical feeder
exchange trolley only
④
Electric feeder bank
feeder exchange trolley type
Electric feeder
Electric feeder exchange
trolley only
Mechanical feeder bank
feeder exchange type and electric
feeder bank feeder exchange
trolley shared type
Mechanical feeder
Electric feeder
Mechanical feeder
exchange trolley
Electric feeder
exchange trolley
6.2. Maximum Number of Feeders Available on a Mounter
1) Mechanical feeders
Feeder name
The number of
feeders available
on the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of slots
occupied
Mounting
pitch
8 mm tape feeder 40 40 80 (80 types) 2 17.0 mm
12 mm tape feeder
26 26 52 3 25.5 mm
16 mm tape feeder
26 26 52 3 25.5 mm
24 mm tape feeder
20 20 40 4 34.0 mm
32 mm tape feeder
16 16 32 5 42.5 mm
32 mm paper
adhesive tape feeder
16 16 32 5 42.5 mm
44 mm tape feeder 10 10 20 8 68.0 mm
56 mm tape feeder 10 10 20 8 68.0 mm
72 mm tape feeder 8 8 16 10 85.0 mm
Stick feeder type N 26 26 52 3 25.5 mm
Stick feeder type W 13 13 26 6 51.0 mm
Stack stick feeder
(Note 1)
5
―
5 8 68.0 mm
Bulk feeder 40 40 80 2 17.0 mm
Note 1: The number of feeders that can be installed on the front side is up to five.
- 35 -
2) Electric feeders
Feeder name
The number
of feeders
available on
the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of lanes
occupied
(Note 1)
Mounting
pitch
4 mm tape feeder
40
40
80 (80 types)
1
17.0 mm
8 mm tape feeder
40
40
80 (80 types)
1
17.0 mm
8-mm double tape feeder
40 40 80 (160 types) 1 17.0 mm
12-mm tape feeder
40 40 80 1 17.0 mm
16 -mm tape feeder
20 20 40 2 34.0 mm
24 -mm tape feeder
20 20 40 2 34.0 mm
32 -m tape feeder
13 13 26 3 51.0 mm
44 -m tape feeder
13 13 26 3 51.0 mm
56 -m tape feeder
10 10 20 4 68.0 mm
Stick feeder type N Note2
20 20 40 2 34.0 mm
Stick feeder type W Note2
13 13 26 3 51.0 mm
Note 1: One lane occupied by electric feeders is mostly equivalent to two slots occupied by mechanical
feeders.
Note 2: Attach the RF_ETF_ATTACHMENT when Stick feeders are used by a feeder trolley (RF)
3) Tray feeders
Feeder name
Dedicated
bank types
The number
of feeders
available on
the front side
The number
of feeders
available on
the rear side
Total number
of feeders
available
The number
of slots
occupied
Tray holder
Full type
For mechanical ― 2 2 42
For electric ― 2 2 42
Half type
For mechanical
―
4 4 21
For electric
―
4 4 21
DTS（TR-1SNR）
For mechanical
―
1(2-sheets) 1(2-sheets) 48
DTS（TR-1EB）
(Note 1) (Note 5)
For electric 1(2-sheets) 1(2-sheets) 48
MTS (TR-5SNX) (Note 1)
― ―
1
(40-stages) 1(40-stages) 80
MTS (TR-5DNX)(Note 1) ― ―
1
(40-stages )
(Note 2)
1(40-stages
(Note 2)
80
MTC (TR-6SNX),
(TR-6SXLX)
(Note 1 and 4)
― ― ―
20-stages
―
MTC (TR-6DNX)
(TR-6DXLX)
(Note 1 and 4)
― ― ―
30-stages
(Note 3)
―
Note 1 : These are dedicated feeders for KE-3020 and KE-3020R. TR-**R series models that have been used
with conventional mounters are not supported.
Note 2 : 40 sheets of 20 types in the nonstop mode
Note 3 : 30 sheets of 15 types in the nonstop mode
Note 4 : TR-6DXLX/6SXLX models are to be used exclusively for a mounter designed for XL-sized board. A
mounter for L-wide board does not support MTC.
- 36 -
6.3. Tape Feeder
6.3.1. Tape feeder for mechanical bank
(
1) CTFR
1) List of specifications
Product
code
Tape type
Feeding pitch
Number of
pins
posting
Diameter of
a reel
Typical component
type
Paper Embossed
CF03HPR
○
－
2mm
Two
φ180 mm
0603
CF05HPR
○ －
1005
CF08HER
－ ○
Two-terminal diode
CF081PR
○ －
4m
m
1608, 2012, 3216
CF081ER
－ ○
SOT
CF8L1PR
○ －
φ180 t
o φ380
mm
1608, 2012, 3216
CF8L1ER
－ ○
SOT
CN05HPR
○
－
2mm
One
φ180mm
1005
CN08HER
－
○
Two-terminal diode
CN081CR
○ ○
4m
m
1608, 2012, 3216
CN8L1CR
○ ○
φ180 t
o φ380
mm
1608, 2012, 3216
* For a tape feeder designed for both paper and emboss, contact our sales person.
* The component size and tape specifications conform to JIS C0806-3:1999 and IEC 60286-3:2007.
*The RFID correspondence of the tape feeder is necessary for using the RFID function of the production
management system.
2) Common specifications
1
Power supply/air supply
None
2
Outer
dimensions
C*0***R
L=602mm, H=208m, W=16.2mm
C*8L1*R
L=683mm, H=431mm, W=16.5mm
3
Mass
C*0***R
1.2 kg (Excluding a reel)
C*8L1*R
1.9 kg (Excluding a reel)
4
Component transport method
Ratchet drive system
3) O
ptions
① Bar code tag
This tag is used to paste a bar code mark onto the rear edge of a tape feeder.
Even after you install a tape feeder on the feeder bank, the pasted bar code can
be read easily.
②
RFID tag mounting kit
By adding a RFID tag to a CTF type o
f tape feeder in use, you can conduct a
feeder management with the production management system.
