5 Tasks at the placement machi ne User manual SIPLACE TX-Series 5.14 Docking the component trolley in or out From software versi on 713.0 Edition 01/2020 274 5 Fig. 5.14 - 1 Safety instructions for docking and undoc king…

User manual SIPLACE TX-Series 5 Tasks at the placement machine

From software version 713.0 Edition 01/2020 5.14 Docking the component trolley in or out

273

5.14 Docking the component trolley in or out

5.14.1 Safety instructions for docking component trolleys in and out

Also follow the safety instructions given in section 2.4.10, page 78.

There is a button at each location (1 and 2). The safety concept for the component trolley change-

over specifies that the operator should push this button at the relevant placement machine loca-

tion, to dock or undock the component trolley.

WARNING

DANGER OF CRUSHING!

Risk of crushing when docking and undocking the component trolley.

 Always dock/undock the component trolley alone.

 When docking and undocking, make sure that there are no body limbs in the travel

area of the component trolley.

PLEASE NOTE

Docking only possible if protective cover is closed

 Close the protective covers.

5 Tasks at the placement machine User manual SIPLACE TX-Series

5.14 Docking the component trolley in or out From software version 713.0 Edition 01/2020

274

Fig. 5.14 - 1 Safety instructions for docking and undocking the component trolley (example of location 2)

(1) Button for docking and undocking the component trolley at location 2

(2) Handles

(T) Direction of PCB transport

(1)

(2)

User manual SIPLACE TX-Series 5 Tasks at the placement machine

From software version 713.0 Edition 01/2020 5.14 Docking the component trolley in or out

275

5.14.2 Docking the component trolley

 Carefully push the component trolley into the placement machine as far as the stop.

 Press the button on the respective placement machine location until the trolley is completely

docked in.

CAUTION

Pushing in component trolley!

 When pushing the component trolley into the placement machine, make sure that

you do not hit obstacles with the locking latches.

PLEASE NOTE

Cut tapes flush

If you do not cut tapes off flush at the front end of the X feeder modules, the emptied

tapes will not enter the empty tape duct.

 Cut the tapes off flush, before you dock the component trolley into place.

CAUTION

Position of placement head!

Check that the placement head is outside the range of the component trolley.
