4 Appendix
4.2 Description of Boards
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2
Prepare Kit 04/2017
78
Connector [03104070-01]
Con-
nector
Designation Terminal
X1 Ground connection "distribution and fusing assembly" From main ground terminal
XB1A Gantry 1 – 24V & signals To gantry cable G1
XB1B Gantry 2 – 24V & signals To gantry cable G2
X2 Diagnostic serial interface (Diagnose Info F&D) To IOCU2 X11 sector 2
X5 FCU 1/2 – 27V DC To FCU1(X111)/2 (X131)
XB5A GCU 1/2 supply To MGCU1 / 2
XB5B GCU3 To MGCU3
XB8A Gantry 1 – 160V DC To gantry cable G1 head
XB8B Gantry 2 – 160V DC To gantry cable G2 head
X24A Star Voltage – 160V From CSB
X24B Safety control signals to FDB – DC42V IN/OUT To CSB
X25 DC 42V IN From AC/DC converter
X26 DC 27V IN From AC/DC converter
XB2 Power Distributor & PC 3D-Sensor – 27V/24V/42V To distributor in sector 2
XB4 Transport To conveyor
