Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
44
7 Hardware Specifications
7.1 Supported Feeder Types
The following feeders are supported by the 706.1 SP2 station software version:
– 8 mm – 88 mm X-feeder
– 2x8 mm X-feeder
– 4 mm X-feeder
– 16 mm XN-feeder
– 104 mm X-feeder
– 12 V2 X-feeder
– Surftape AX (8 mm, 12 mm, 16 mm)
– LED feeder TE
LED feeder HS
– Glue Feeder
– TrayStak Feeder AX (X4i S on location 2 and 3 only)
– Arbitrary Carrier X (only X-series)
– Carrier X (XTH) (X2, X3, X4 on location 2 and 4 only)
– Carrier SX (SX1/SX2 with Twin Head and CPP head only)
– FFI feeders:
HanSan LED feeder
Top Engineering LED feeder
Data IO RoadRunners
– IPTE Multi Stick Feeder:
IPTE multi stick 60 AX
IPTE multi stick XL80 AX
– Stick feeder with X-adapter
– Label feeder with X-adapter
– Reject conveyor with X-adapter
– Dip module for X-tables (LDU_X)
– MTC2 (X2, X3, X4 on location 2 and 4, X3 S on location 2, X4 S)
– WPC5 (only SX1/SX2)
– WPC6 Non Stop Module (SX1/SX2 only)
– Splice sensor X-feeder
Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
45
7.2 Digital Camera Systems
Digital CCD cameras are used as the camera systems.
7.2.1 Component Cameras
All heads are equipped with the standard camera listed below. High-resolution cameras are
additionally available for Twin Head and CPP.
Component camera Camera
type
CPP
type
C&P20A
head
Twin
Head
VHF P&P
head
C&P12
head
C&P
6 x 6 mm digital
23
-
(default) -
-
C&P
6 x 6 mm digital
41
-
(optional) -
-
C&P
18.7 x 18.7 mm digital
28
(optional) - -
(default)
C&P
27 x 27 mm digital
29
(optional) - -
-
C&P
27 x 27 mm digital
30
(default) - -
(optional)
C&P
16 x 16 mm digital
38
(optional) - -
-
Stat. P&P
16 x 16 mm digital
2
)
25
- -
(optional)
(optional) -
Stat. P&P
55 x 45 mm digital
2)
33
(optional)
1)
-
(default)
(optional) -
Stat. P&P
32 x 32 mm digital
36
(optional) -
(optional) -
Table 7-1: Component cameras
1)
Only together with CPP head, with which components up to a height of 11.5 mm can be placed.
2)
Is not supported on the SIPLACE X4i placement machine.
7.2.2 Board Cameras
Board camera Camera type SIPLACE X-series SIPLACE SX-
series
SIPLACE DX-
series
28 digital 34 (default) (default) (default)
28 digital 34 H (default)
1)
Multicolor 28 digital 24 (optional)
Table 7-2: Board cameras
1)
Only supported on the SX1/SX2 V2 placement machine.
Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
46
7.3 Component Range
Component
range for
CPP head
With type 28
component
camera
(C&P 18,7 x
18,7 mm
digital)
With type
29
component
camera
(C&P 27 x
27 mm
digital)
With default
type 30
component
camera
(C&P 27 x
27 mm
digital)
With type 38
component
camera (C&P
16 x 16 mm
digital)
With type 33
component
camera (Stat.
P&P 55 x 45
mm digital)
With type 36
component
camera (Stat.
P&P 32 x 32
mm digital)
0402
through 18.7
x 18.7 mm
01005
*)
through 27
x 27 mm
01005
through 27
x 27 mm
01005
through 16 x
16 mm
(0603)
through
55 x 45 mm
0603 through
32 x 32 mm
Nozzle types 20xx, 28xx
Table 7-3: Component range CPP head
*)
If components with an edge length between 0.19 and 0.26 mm are taught, a warning is displayed,
that the placement quality may be less than specified.
Component range for
C&P20A head
With default type 23 component
camera (C&P 6 x 6 mm digital)
With high-resolution type 41
component camera (C&P 6 x 6
digital)
01005 through 2220 01005 through 2220
Component
specification
min dimenstions
0.18 x 0.18 mm 0.12 x 0.12 mm
max. dimensions
6 x 6 mm (incl. component
tolerances)
6 x 6 mm (incl. component
tolerances)
min. lead pitch
0.25 mm 0.08 mm
min. lead width
0.1 mm 0.03 mm
min. ball pitch
0.4 mm 0.1 mm
min. ball diameter
0.2 mm 0.,05 mm
Field of vision
8.4 x 8.4 mm
2
8.9 x 8.9 mm
2
Method of illumination
Front-illumination (5 levels,
programable as required)
Front-illumination (5 levels,
programable as required)
Nozzle types 10 xx, 11 xx, 12 xx 10 xx, 11 xx, 12 xx
Table 7-4: Component range C&P20A head
