Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition

10 Corrected Errors

10.1 706.1 SP2 Station Software

Station software version 706.1 SP2 contains all the error corrections of the previous versions

701.xx – 706.1 SP1. Additionally, the following errors have been corrected in this version:

Error no. Error description

D1-74832811

Height control errors frequently occured when the trays were returned into the

tower.

D1-78661201 The MTC did not consider the acceleration reduction.

D1-79243301 Too long time for downloading a new recipe and setup to the station.

D1-80541901

D16837-1398

This error occurred sporadically when the machine was started:

Head configuration not supported for this machine. Can't

initialize machine hardware

D1-81048513

D1-85016987

The "Name" column displaying the placement reference position was missing

in the 706 station software.

D1-82180701

The nozzle was out of center in front of the component camera after a feeder

change and the track was deactivated.

D1-83201901 The machine stopped the production after not having recognized an ink spot.

D1-83344201 The placement position could not be taught.

D1-84180931 Misleading error message for measurement errors during calibration.

D1-84221817 The MTC reference run failed on an X3 S placement machine.

D1-84355807 The cutting unit did not work if only X-feeders 56-88mm were set up.

D1-84734801

D1-86050901

D1-86095301

D16775-4658

After sending a new product the feeder position recognition sporadically failed.

D1-84955201

eSW: the board was not transported to the output conveyor after the conveyor

width had been adjusted

D1-85017141 Sporadically, there were some question marks in the PCB conveyor view.

D1-85076201

The "Feed forward" function did not work when the pickup position was

checked.

D1-85401001

The machine displayed error message 30464 Current of servo

amplifier or motor exceeds threshold

D1-85401043

eSW: error message 40006 Board cannot reach target position

although the board was over the sensor.

Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition

Error no. Error description

D1-85847311

Holding vacuum values were not displayed correctly when the filter plates

were tested.

D1-85871081 eSW: BIOS V01.01 for the LDU was missing in the eSW pool.

D1-85873213 Empty pin garages were not displayed correctly.

D1-86009357

D1-86920701

The calibration was aborted with a conveyor error after a gantry exchange.

D1-86174924

D1-87501501

The machine stopped during production and could not be started again.

D1-86190301

D1-85897301

D16575-6907

After the first installation of 706.1.SP1 C&P20A heads were no longer

recognized.

D1-86194907 The BUG report was visible in the background.

D1-86349451

For multiple set-up components the "Feeder is missing" display failed for not

positioned components.

D1-86351372

D1-86357901

The pick-up position got inaccurate after a while.

D1-86377401

D1-86551501

The extended interface was not offered within the conveyor configuration.

D1-86379401

In the placement list the options could only be changed by SIPLACE service.

Customer service should also be allowed to do this.

D1-86394915 Feeding on demand for 1x8 and 2x8 X feeders did not work properly.

D1-86404401

eSW: the mounted board was not transported due to an error in the control

voltage.

D1-86432701

The support pin in the pin magazine was not recognized on an X4 S

placement machine.

D1-86616801 The nozzle ID of nozzle type 2020 was not recognized.

D1-86654502

eSW: Machine was locked after a moving error and manual removement of

the PCB from the output conveyor.

D1-86736801

D1-82577101

It was possible for the operator to log out directly from the GUI under

Windows 7.

D1-86762641 The machine got into an infinite loop during the firmware upgrade.

D1-86788354 eSW: hang-up due to activation of watchdog conveyor control board.

D1-86894185

eSW: the board was not transported into the next machine although the

conveyor was empty.

D1-86897701

D16901-8007

D17049-6511

An X4 placement machine (with Twin + CPP) reported an error: 30470 Either

collision of two gantries or axis hit bumper at end of driving range.

D1-86926901 eSW: removing a board did not work correctly.

D1-86988501

eSW: the FCU sub-system was not responding and the table was no longer

reachable.

Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition

Error no. Error description

D1-87381901

Different values for the gantries during the zero compensation of the pressure

control on an X4 S placement machine.

D1-87407611 Incorrect nozzle angle for the pickup.

D1-87625301

After software installation the machine started with an unexpected error and

Windows had to be restarted.

D1-87625341 The machine detected new heads after calibration.

D1-87699101

D1-88063501

Dirty nozzles were rejected on an X4 S placement machine although the

corresponding settings were deactivated.

D1-87736101

An X3 S placement machine could not be put into operation because the

machine searched for a non-available nozzle changer.

D1-87848301 Pin picker magazines without a board were not recognized by the software.

D1-87988601

D1-84260938

D1-87501541

The machine stopped during placement and the Start button had to be

pressed to continue.

D1-88005501 Production in production area 2 stopped suddenly.

D1-88384401

X S-series placment machines threw away bigger components at the wrong

position.

D16223-6711

D1-58494401

D1-60422901

D1-67917601

D16849-4907

D16747-5948

Different cycle times in SIPLACE Pro and on the machine.

D16600-2278 eSW: Auto recovery failed in lane1 after the machine restarted.

D16600-2333 The machine stopped during normal production.

D16633-4310 eSW: WPC 6 with non-stop module stopped during production run.

D16714-1610

After an MTC error the operator was prompted to terminate Windows and

restart the machine.

D16771-9107 eSW: sporadically, feeders were unlocked.

D16803-9613

D1-80501601

D17056-1807

Sporadic software crash when components were taught.

D16837-1398

Machine hardware could not be initialized (placement head configuration not

supported for this machine type after exchange of a segment).

D16865-3207 eSW: Enhancement of the robustness when the dp axis was positioned.

D16878-9009 The support pin was incorrectly positioned by the pin picker.

D16878-9809

D17186-410

eSW: X4 S: lane1 PA1 PCB was placed twice.
