Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
65
Error no. Error description
D1-82588449 Flash behavior of the green lamp indicator changed during product change.
D1-82604011 Unhandled Exception within SirioConsole.exe.
D1-82620574 Unknown placement state.
D1-82620901 Teaching the zero point of the machine was inverse to the Vision display.
D1-82633901 The "Loading board" function was aborted with an error message for the
embedded software.
D1-82747057 After timeout for the DP axis, the station had to be rebooted.
D1-82759001
D1-82597601
Coplan MFU did not function on an SX1/SX2 placement machine.
D1-82793701 Conveyor lane 2 was locked although a job was defined.
D1-82802953 Sporadically, the GUI did not start after a reboot.
D16901-4109 eSW: 12/16mm X smart feeders sporadically reported foil broken errors
although there was no foil torn.
Table 10-2: Corrected errors 706.1 SP1 station software
Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
66
10.3 706.1 Station Software
Station software version 706.1 contains all the error corrections of the previous versions
701.xx – 706.0. Additionally, the following errors have been corrected in this version:
Error no. Error description
D1-62595101 Troubleshooting difficult because no component name was displayed für the
placement heads and segments in the error message for the z-axis.
D1-63468662 The tray was feeded in spite of the refill position.
D1-63494246 The pick-up angle at the MTC2 was not transferred to SIPLACE Pro even though
uploading was activated.
D1-64522301 An SX2 placement machine stopped after 2.5 hours nighttime run with an error
message that the z-axis could not be moved to a safe position.
D1-66198001 An incorrect pick-up position was approached in the tray.
D1-66633301 The station software hung up after the teaching of a component shape failed.
D1-66918811 Too big difference between two component sensor values on C&P20 placement
heads on an X4 placement machine.
D1-67030701 It was not possible to move to the refill position during production.
D1-68408901 A table at an SX-series placement machine could not be docked as the cover was
opened. The "Unspecified hardware error" message was misleading.
D1-69233218 Traveling parameters could not be set for the axis.
D1-69239712
D1620-8901
The CPP placement head wiped off tall components on an SX-series placement
machine.
D1-70141578 A missing tray in the WPC was not marked in red on the GUI of the station
software.
D1-70180045 After the width had been adjusted, the current width was not displayed.
D1-70928401 After the 3D coplanarity measurement, a component was not put back correctly into
the tray.
D1-71252701 At a track error on an X3 placement machine the wrong lamp indicator was
illuminated.
D1-72413212 An error message about a potential gantry collision was displayed after the cover
had been opened and closed on an X4 placement machine.
D1-73126941 Smart Pin Support did not function in safe mode.
D1-73291201 Smart support pins could not be automatically positioned.
D1-73637347 During teaching, an incomprehensible error message was displayed:
Machine position no longer exists
.
D1-73678601 When the pick-up position was taught, it was shown displaced by approximately
1mm, depending on whether the Show entire component option was enabled or
disabled.
D1-73895501 The station software hung up after the position recognition on an X4i placement
machine.
D1-73895600
D1-73126901
D1-74130301
D1-76087441
The 32434 and 32433 error messages were displayed in connection with Smart
Pin Support. No components were present on the underside of the board.
Station Software 706.1 SP2/705.05 SP2 / Version Description Ausgabe 07/2013 Edition
67
Error no. Error description
D1-73931701 The pin picker could not be calibrated, because the support pin was too closely
positioned to the conveyor.
D1-73963801 An SX-series placement machine could not be initialized and had to be rebooted.
D1-74085991 After a board had been assembled in Recovery mode and the same program was
downloaded from SIPLACE Pro to the placement machine, this setup was not
completed.
D1-74361401 Air pressure adjustment only functioned if the air pressure deactivation was
enabled.
D1-74610501 The traveling range could not be measured.
D1-74674301 An SX-series placement machine with a loaded board stopped without any error
message. Thereafter, the keyboard did not function correctly.
D1-74774701 For user-defined settings of the fixed rail, values between 0.00 and 0.00 were
available only.
D1-75917101 The x-axis position was outside the traveling range.
D1-76104851
D1-76657847
Head mapping error on an SX-series placement machine.
D1-76146401 The number of cycles was too high for the Smart Pin Support endurance run.
D1-76359294
D1-76320101
D1-76359201
D1-76359252
D1-76712470
If the 2x8mm X-feeder was positioned on another track, this was not identified as
an alternative track by the station.
D1-77925001 Error message during production: Bottom light barrier triggered even
though positioning mode is absolute
.
D16273-9267 When many error information messages were displayed on the GUI simultaneously,
the screen slowed down a lot.
Table 10-3: Corrected errors 706.1 station software
